PLC
|
Germany SIEMENS
|
|
Triplet
|
TAIWAN AIRTAC
|
|
Low voltage electrical apparatus
|
Germany SIEMENS
|
|
Solenoid valve
|
TAIWAN AIRTAC
|
|
Sensor
|
Korea AUTONICS
|
|
Gas driller
|
Taiwan BOA
|
|
Guide
|
Taiwan TBI
|
|
Switch power
|
Taiwan TEND
|
LJTB03 Butyl extruder machine
Main feature
n PLC control system, touch screen interface.
n Frequency control system
n Abroad technology, pneumatic and hydraulic supercharging system.
n Automatic centering and clamping structure.
n Separate extruder head structure.
n Automatic butyl volume display function.
n Circular arc butyl sealing structure.
n Extruder head height adjustment structure
n Preheating function
n Butyl cylinder swing mechanism
n Important control parts adopt imported brand.
Main technical parameter
| Squeeze pressure |
10-14MPa |
| Temperature |
110-140ºC |
| Aluminum spacer width |
6-24mm |
| Speed |
0-27m/min |
| Diameter of butyl cylinder |
190mm |
| Air supply |
Flow:0.4m/min |
| Air pressure |
≥ 0.8MPa |
| Total power |
220V 50HZ 2.5KW |
| Dimension |
3000*620*1102mm |
Spacer bending machine
l 1*1m spacer frame was bend around 17s.
The error of spacer frame angle is within 0.1mm.
l Can bend aluminum spacer /technoform /Alupro /thermix/
l Spacer automatically connect and cut.
l Machine automatically stop when the spacer use up.
l Support continuous bending , automatically avoid spacer connection while bending and cutting
l Automatically connect the spacer -connector
l Remote control function
l USB input function ,it can read the excel data directly
l Spare parts of all machine have ID code ,convenient for after-sale service
l Heavy duty connectors ,convenience and safety for installation and debugging
l Magnetic valve use Taiwan Airtac
l German Siemens plc control systerm
l Japan Fuji servo control system
l 12 storage spacer units (option)
l Swisspacer/ Stainless Steel /Allmetal Stainless Steel /option)
(Stainless steel and warm edge spacer can not exist at one time )
l Drill hole for gas filling(option)
l Spacer inkjet printing ,various color is available for company logo or production date(option)
l Laber printing (option)
l Scanner scan two-dimension code ,bar code (option)
l Separate Pressing Wheel for arc frame, more accurate than the bending tool
Especially for Hexagon and Octagon frame (optional )
l ERP (optional)
