High Speed Butyl Extruder Machine For Insulating Glass Non-Adhesive Belt

Large Image : High Speed Butyl Extruder Machine For Insulating Glass Non-Adhesive Belt

Product Details:

Place of Origin:	China
Brand Name:	LIijiang Glass
Certification:	CE
Model Number:	LJTB01

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD 13000.00 - 11000.00
Packaging Details:	Container/wooden box
Delivery Time:	45 days
Supply Ability:	50sets/month

Contact Now

High Speed Butyl Extruder Machine For Insulating Glass Non-Adhesive Belt

Description

Voltage:	Customized	Warranty:	1 Year
Dimension(LWH):	26006801100mm	Aluminum Spaer Width:	5-27mm
Gluing Speed:	2-50m	Air Pressure:	>0.6MPa
Color:	Customized
Highlight:	High Speed Butyl Extruder Machine , Insulating Glass Butyl Extruder Machine , High Speed hot melt butyl machine

Butyl Extruder Machine LJTB 01

The LJTB01 butyl extruder machine is used for spreading aluminum spacer frames evenly with hot melt butyl. This equipment use large electrical control panel which makes the operation more easier. The conveyor of aluminum is controlled by frequency

converter, and the speed can be adjusted from 0m/min to 47m/min, which has the fastest speed in China. It is very popular with

energy-saving. Its squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable.

The dispensing cylinder uses vertical rotary support system and it makes the refill of butyl easier. It can prolong the life of squeezing system and set the heating time in 24 hours with electricity and air pressure. The distance of squeezing head can be adjusted automatically according to different aluminum spacer. The machine has reached the worldwide technology with the characteristic of complete function and stable working mode.

Parameters


			Squeeze pressure

			10-18MPa

			Temperature

			110~140℃

			Aluminum spacer width

			4-30mm

			Speed

			0-47m/min

			Diameter of butyl cylinder

			200mm

			Air supply

			0.4m³/min

			Air pressure

			≥0.6MPa

			Total power

			380V, 5KW, 50HZ

			Dimension

			2600×680×1100mm(L×W×H)

			Weight

			650kg

Features

Filter out debris automatically through auto exhaust, keep spreading quickly and evenly.

Quickly speed of warming, improve work effect.

Adjustable coating speed, can up to 0-47m/min.

Can save about 40% materials, only 5g/m.

Extruder head height adjustment structure.

Automatic centering and clamping structure.

Stable temperature and it is convenient to adjust the sealing material automatically.
