Product Details:
|
| Production Name: | Automatical Molecular Sieve Filling Machine | Faction: | Automatically Drilling,filling And Sealing |
|---|---|---|---|
| Application: | Double Glazing Glass Making | Filling Aluminum Frame's Maximum Size: | 2000mm*2000mm |
| Filling Aluminum Frame's Minimal Size: | 300mm*250mm | Molecular Sieve Diameter Needed: | 0.5- 0.9 Mm |
| Optional: | Big Barrel | Weight: | 300kg |
| High Light: | plc Molecular Sieve Filling Machine,PLC Control Molecular Sieve Filling Machine,PLC Control Desiccant Filling Machine |
||
Automated Molecular sieve filling machine Adopt Japan ANCHUAN servo control system with stable performance,it can Automatically measure glass size, glue depth and glue speed with linear adjustment, coating glass with silicone,glass corners are full without air bubbles, smooth surface. Big plastic barrel is option,save feeding time and improve efficiency.
Advantage of Automatic molecular sieve filling machine
•Automatic desiccant filling machine adopt Siemens PLC control system,stable performance
•Automatically drilling,filling and sealing
•Touch screen interface, simple and visible
•with the guide rail lifting device is option
Details of Automatic Molecular sieve Filling Machine
1.Auto drilling, filling and sealing function,Automatically loading and replenishmolecular sieve
2.Germany SiemensPLC controlsystem,stableperformance,Electrical component are all Germany Brand-Siemens.
3. Adopt industrial plastic spraying treatment of all racks,Protection device for machine head.
4.Desiccant filling Machine height can be adjusted according to the size of spacer frame
5.All the electrical wires have the ID number,it can match with specification , also it will be convenient for the further communication in the after sales service .
6.Desiccant automatically loading from the Materials bucket.Automatically loadingand replenish molecular sieve
Technical parameter of Automatic Molecular sieve filling machine
| Filling aluminum frame’s maximum size | 2000mm*2000mm |
| Filling aluminum frame’s minimal size | 300mm*250mm |
| Article aluminum specifications | 5.5-26.5mm |
| Air source | ≥0.65MPa |
| Power supply and power consumption | AC220V 50Hz 1.8KW |
| Molecular sieve diameter needed | 0.5-0.9mm |
| Dimension | 1300mm*1050mm*3650mm |
Related products
Vertical Insulating Glass Sealing Robot LJTJ2540
Main Features:
• Min & Max glass sizes can be optional
• Adopt 8 servo motors
• Adopt Japan servo control system with stable performance
• Automatically measure glass size, glue depth and glue speed with linear adjustment
• Adopt timing belt to keep smooth convey with accurate position
• Spares are produced with high standardization and high precision, ensure the machine can be used with long-term working
• The glass corners are full without air bubbles, smooth surface, no need to
• Full automatic and high-efficiency machine
• Automatically repair glass corners with beautiful surface
• Smooth convey without scratch and pollution
• Single-function parts are equipped with manual functions, easy adjustment
• Can coating more than 8 kinds of shaped glass, include Semicircle. Trapezoidal. Parallelogram. Circular. Polygon, etc (Optional)
• Seal stepped glass fully at once (Optional)
• Can seal stepped IG with four sides (Optional)
• Adopts double pumps device to use two kinds of different sealants, such as silicone, polysulfide and silicone structural sealant (optional)
Technical data
| Max. glass size | 2500*4000mm (Optional) |
| Min. glass size | 300*300mm |
| Glass thickness | 12-50mm |
| Working speed | 5-40m/min |
| Air pressure | ≥0.6MPa |
| Squeeze pressure | 32MPa |
| Voltage power | 380V 12kw |
| Overall dimension | 11000*2000*3500mm |
Electrical parameters
| NAME | ORIGIN | BRAND |
| Servo motor | Japan | YASKAWA |
| Servo driver | Japan | YASKAWA |
| CPU | Japan | YASKAWA |
| Low voltage component | Germany | SIEMENS |
| Guideway | Taiwan | HIWIN |
| Switching power supply | Taiwan | MW |
| Sensor switch | Korea | AUTONICS |
| Pneumatic component | Japan | SMC |
| Touch screen | China | GAOSHAN |
| Servo motor | Japan | YASKAWA |
| Servo driver | Japan | YASKAWA |
Vertical Low-E Glass Edge Deletion Machine LJCM2545
Main feature
• Two-way glass access
• Automatically measure size
• Automatically distinguish low-e surface
• Edge deletion is adjustable
• Safe and full automatic device
• PLC control system, touch screen interface
• Six servos control system
• Intelligent control system, can recognize batch processing
Technical data
|
Max. glass processing size |
2500*4500mm |
|
Min. glass processing size |
400*280mm |
|
Glass thickness |
3-15mm |
|
Diameter of grinding wheel |
200mm |
|
Conveyor height |
500mm |
|
Edge deleting width |
10-50mm |
|
Transmission speed |
1. 29m/min |
|
Edge deleting speed |
2-29m/min |
|
Abrasive wheel width |
10/12/15mm |
|
Glass thickness |
3 - 15mm |
|
Grinding wheel speed |
0~3000r/min |
|
Total air consumption |
100L/ min |
|
Air pressure |
≥0.8MPa |
|
Total power |
3P 380V 50Hz 3.35KW |
|
Dimension |
Dimensions :9700×2500×3400mm |
|
Total weight |
3700KG |
