Product Details:
|
| Name: | Molecular Sieve Of Insulating Glass | Size: | Diameter 0.3cm |
|---|---|---|---|
| Characteristics: | High Strength,High Adsorption Capacity,Particle Uniformity | ||
| High Light: | glass filling machine,desiccant filler |
||
Process flow:
Washing→Filterpressing→Crushing→Forming→Health maintenance→Drying→Activation
Technical Parameter:
| Model | 5A Molecular Sieve | |||
| Nominal pore diameter | 5 angstroms | |||
| Shape | Sphere | Pellet | ||
| Diameter | 1.7-2.5 (mm) | 3.0-5.0 (mm) | 1.6 (mm) | 3.2 (mm) |
| 8*12 (mesh) | 4*8 (mesh) | 1/16 (inch) | 1/8 (inch) | |
| Bulk density (g/ml) | ≥0.66 | ≥0.66 | ≥0.64 | ≥0.64 |
| Crushing strength (N/PC) | ≥30.0 | ≥70.0 | ≥30.0 | ≥50.0 |
| Size ratio up to grade (%) | ≥96.0 | ≥96.0 | ≥96.0 | ≥94.0 |
| Static H2O adsorption (%) | ≥21.0 | ≥21.0 | ≥20.5 | ≥20.5 |
| Static Hexane adsorption (%) | ≥12.0 | ≥12.0 | ≥12.0 | ≥12.0 |
| H2O content (%) | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 |
| Wear ratio (%) | ≤0.20 | ≤0.20 | ≤0.40 | ≤0.40 |
5A Molecular Sieve, has an effective pore opening of 5 angstroms(0.5nm).
It will adsorb molecules with a kinetic diameter of less than 5 angstrom and exclude those larger.
It has high select adsorption and fast adsorption speed.
Typical Application:
a) The various sizes of O2, H2, CO2 and other gas PSA devices.
b) Separation of normal paraffin and isoparaffin.
c) The purification of air, dehydration and carbon dioxide removal.
d) The drying of natural gas, dehydration and desulphurization.
Characteristics:High strength,High adsorption capacity,Particle uniformity
Storage:room temperature;Relative humidity is not more than 90%;Should not be directly exposed to the air;Avoid water,acid and alkali.
Regeneration:
1. Moisture removal:depending on the temperature,pressure and water content of the gas.In general,the dry gas at 200-350℃ passes through the molecular sieve bed at a pressure of 0.3-0.5kg/cm2 for 3-4 hours,bringing the outlet temperature to 110-180℃ and cooling.
2. Removal of organic matter:replace organic matter with water vapor,and then remove water.
Packaging Details
Paper bag, super sack, steel drum with wooden pallet for zeolite 3a
Port:Qingdao,Tianjing, Shanghai, etc.
Lead Time:7-10 days after receiving your deposit or your workable LC
