DRYER FILLIER FOR INSULATING GLASS MACHINE DOUBLE GLAZING GLASS MACHINE

DOUBLE GLASS DRYER  FILLING MACHINE FOR INSULATED GLASS9(MOLECULAR SIEVE 0.5-0.9mm/1.0-1.5mm )





Main feature



1, The filling height of Desiccant filling machine can be adjusted according to the size of spacer frame



2, Desiccant filling machine Filling time can be adjusted



3, Desiccant filling machine auto loading and replenish



4, ADesiccant filling machine auto drilling, filling and sealing function



5,  Germany Siemens PLC control system



6, Touching screen interface, simple and visible



7, Adding glue way is safe and easy



8,  Machine can fill the arc frame.(optional function)



9,  Can fill Molecular sieve diameter 1.0mm-1.5mm(optional function)



Main technical parameter



Filling aluminum frame’s maximum size	2000mm*2000mm
Filling aluminum frame’s minimal size	300mm*250mm
Article aluminum specifications	5.5-24mm
Air source	≥0.65MPa
Power supply and power consumption	AC220V 50Hz 1.8KW
Molecular sieve diameter needed	0.5-0.9mm
Dimension	1300mm*1100mm*3650mm



Desiccant filling machine main component



name	brand
PLC	German SIEMENS
Low voltage electrical apparatus	German SIEMENS
sensor	Korea AUTONICS
guide	Taiwan TBI
triplet	TAIWAN AIRTAC
Solenoid valve	TAIWAN AIRTAC
Gas driller	Taiwan BOA
Switch power	Taiwan TEND



LJGZ2020A Automatic desiccant filling machine



Main feature



n The filling height of can be adjusted according to the size of spacer frame



n Filling time can be adjusted



n Desiccant auto loading and replenish



n Auto drilling, filling and sealing function



n Germany Siemens PLC control system



n Touching screen interface, simple and visible



n Adding glue way is safe and easy



n Machine can fill the arc frame.(optional function)



n Can fill Molecular sieve diameter 1.0mm-1.5mm(optional function



n Big bucket desiccant ,save desiccant refill time ,improve the work efficiency (optional function)



n Protection device for machine head ((optional function)



n Adopt vacuum pump loading device ,increase the loading speed (optional function)







We have our own china domestic team and oversea service team .

Whole team was included by 15 china engineers who worked in glass machine filed more than 20 years and 5 oversea engineers , two of them from india and others from south America and midle east.

24 hours online service and local engineer available , guarantee customers got timely service and solution .

National Glass Expo

Glasstec in Germany ,

CAM Eurasia Glass in Istanbul,

India Zak,

India Glasspro,

Glasstech Aisa ,

Glass build in America,

Mexico glass expo .

Big Five In Dubai,

Egpyt.

Domestic glass expo :

China glass , (Beijing /shanghai),

Guangzhou.



















Vertical Insulated Glass Produce Line for double glass production line

Auto Sealing Robot for double glass production line

Sealant Spreading Machine for double glass production line

Low-E Glass Washing &Drying Machine for double glass production line

Smart Edge Deleting Machine for double glass production line

Automatic Spacer Bending Machine for double glass production line

Automatic Desiccant Filling Machine for double glass production line

Butyl Extruder Machine for double glass production line

Glass Edge grinding Machine for double glass production line

Spacer Cutting Machine for double glass production line

Sealing gun Freezer for double glass production

Rotated Sealant Spreading Table double glass sealing

Argon Gas Filling Machine double glass

Semi-auto Aluminum Frame Transfer Machine for double glass production line

Molecular Sieve Filling Machine double glass production line

Glass Lifting Table double glass production line

Glass Loading /unloading Device for double glass production line

Water Treatment System for double glass production line (Economy)

Water Treatment System double glass production line (Advanced)

Auto Seaming Machine























Service Team:



We have our own china domestic team and oversea service team .

Whole team was included by 15 china engineers who worked in glass machine filed more than 20 years and 5 oversea engineers , two of them from india and others from south America and midle east.

24 hours online service and local engineer available , guarantee customers got timely service and solution .













JINAN LIJIANG QUTOMATIC EQUIPMENT CO.LTD is an enterprise which integrated DGU Machines development, designing, sale and service into a whole. The company is located in the beautiful spring city, Jinan. Because it is close to Beijing-shanghai high-speed railway line, it’s very convent for transportation.

The company adheres to the “Hi-Q products”. We are striving to create the top-grade DGU Machines through setting up technology research and development center, inviting some experts to guide. We also cooperate with the domestic well-know enterprises and actively import foreign advanced technology. Now our company are the main supplier of glass deep processing enterprises in China. Our DGU machines are used by the main domestic famous glass factories, such as NORTH GLASS, XIN FU XING GLASS,YAO HUA GLASS, DALIAN HUAYING GLASS etc. We also have more than 400 customers who use our DGU machines in China. We have got CE certification in 2017. So far our machines has exported to more than 30 countries and regions, just like Europe, South America, Middle East, Southeast Asia and so on.

At the same time, our company cooperates with scientific research institution, which is based on research and development center, imported advanced intelligence. Our company successively cooperates with institution of China North Industries Group and Shandong University in order to develop more new products. Now we have already successfully produced vertical insulating glass production line, vertical insulating glass sealing robot and new butyl extruder machine, which quality has reached the domestic top-grade level.

LIJIANG GLASS are goes into a leading way in the DGU mechanical field with the advanced technology, first-class products, perfect service and good reputation!
