Product Details:
|
| Squeeze Pressure: | 10-14Mpa | Temperature: | 110°-140° |
|---|---|---|---|
| Spacer Width: | 6A-24A | Speed: | 0-27m/min |
| Diameter Of Butyl Cylinder: | 190mm | Air Supply: | 0.4m³/min |
| Air Pressure: | ≥0.8Mpa | Total Power: | 220v/380V,2.5KW,50HZ |
| Dimension: | 3000*620*1102mm | Name: | Butyl Extruder Machine |
| Warranty: | 1 YEAR | Condition: | New |
| High Light: | butyl silicone sealant,double glass machine |
||
Automatic Butyl Extruder Machine
LJTB03
LJTB 03 Automatic butyl extruder machine is used for spreading aluminum spacer frames evenly with hot melt butyl. The butyl extruder uses large electrical control panel which makes the operation more easier than before. The conveyor of aluminum is controlled by frequency converter. The speed can be adjusted from 0m/min to 47m/min, it is the fastest speed in China until now. The butyl extruder is very popular with energy-saving. Its squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable. The dispensing cylinder adopts vertical rotary support system, making the refill of butyl more easier. The height of squeezing head can be adjusted automatically according to different kinds of aluminum spacers. Finally, the butyl extruder has reached the worldwide technology with the characteristic of complete functions and stable working mode
.
Main components
| Name | Brand | Original |
| PLC | KINCO | China |
| Valve | HAWE | German |
| Low voltage electrical apparatus | SIEMENS | German |
| Hydraulic and pneumatic supercharging system | MAXIMATOR | German |
| Frequency converter | KINCO | China |
| Pneumatic components(cylinder/valve) | ARTAC | Taiwan |
| Quick exhaust valve/Vacuum generator | SMC | Japan SMC |
| Travel light | OMRON | Japan |
| Optical fiber | OMRON | Japan |
Detail
FAQ
1.Question:The delivery time ?
answer: normally no more than 10 days
