semi-automatic butyl extruder machiine for insulating glass production line

semi-automatic butyl extruder machiine for insulating glass production line
semi-automatic butyl extruder machiine for insulating glass production line semi-automatic butyl extruder machiine for insulating glass production line semi-automatic butyl extruder machiine for insulating glass production line semi-automatic butyl extruder machiine for insulating glass production line semi-automatic butyl extruder machiine for insulating glass production line semi-automatic butyl extruder machiine for insulating glass production line

Large Image :  semi-automatic butyl extruder machiine for insulating glass production line

Product Details:
Place of Origin: China
Brand Name: LIJIANG
Certification: CE
Model Number: LJTB 01
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD12000/set
Packaging Details: wooden box
Delivery Time: 5-8work days
Payment Terms: L/C, T/T
Supply Ability: 30sets/month

semi-automatic butyl extruder machiine for insulating glass production line

Description
Name: Butyl Extruder Machine Squeeze Pressure: 10-18MPa
Temperature: 110~140℃ Aluminum Spacer Width: 4-30mm
Speed: 0-47m/min Diameter Of Butyl Cylinder: 200mm
Air Supply: 0.4m³/min Air Pressure: ≥0.6MPa
Total Power: 380V, 5KW, 50HZ Dimension: 2600×680×1100mm(L×W×H)
Weight: 650kg
High Light:

butyl silicone sealant

,

double glass machine





Butyl extruder machine LJTB01

semi-automatic butyl extruder machiine for insulating glass production line 0


Overview

semi-automatic butyl extruder machiine for insulating glass production line 1
Extrusion coating machine LJTB 01 automatic butyl rubber extruder is used to disperse aluminum gaskets (and other gaskets) evenly with hot melt butyl rubber. The butyl extruder uses a large electrical control panel, which is easier to operate than before. The speed can be adjusted from 0m / min to 47m / min, which is by far the fastest speed in China. Butyl rubber extruder is very popular in energy saving. The extrusion system adopts German pneumatic and hydraulic pressure boosting system to make the extrusion pressure more stable. Butyl rubber extruder has achieved world-class technical level with its complete functions and famous spare parts.





product features




  • Hot melt butyl extruder adopt PLC control system, touch screen interface.
  • Automatic recognition of the width of the aluminum belt, the glue nozzle can be adjusted automatically.
  • The key parts of the hydraulic system use components imported from Germany to ensure even plastic filling.
  • Quick warm-up to improve work efficiency.
  • With preheating function.
  • With exhaust gas inflation function, improve the sealing quality and save plastic time.
  • Fast coating speed, up to 47m / min.
  • Save glue.



Using non-adhesive belt, keep clean.

semi-automatic butyl extruder machiine for insulating glass production line 2



Crossbeam adjustable structure controls the spreading height.

semi-automatic butyl extruder machiine for insulating glass production line 3



The special part controls both sides of nozzle opening and closing at the same time.

semi-automatic butyl extruder machiine for insulating glass production line 4


Automatically filter debris and air, keep spreading evenly.

semi-automatic butyl extruder machiine for insulating glass production line 5



Parameter

Squeeze pressure10-18MPa
Temperature110~140℃
Aluminum spacer width4-30mm
Speed0-47m/min
Diameter of butyl cylinder200mm
Air supply0.4m³/min
Air pressure≥0.6MPa
Total power380V, 5KW, 50HZ
Dimension2600×680×1100mm(L×W×H)
Weight650kg






About the company

semi-automatic butyl extruder machiine for insulating glass production line 6

Jinan Lijiang Automation Equipment Co., Ltd. (Lijiang Glass Factory) is located in the beautiful spring city of Jinan. It is an enterprise integrating R & D, sales and service of glass processing equipment. Due to the proximity to the Beijing-Shanghai high-speed rail, the transportation is very convenient.

The company is committed to drawing on the experience of famous experts, establishing a research and development center, cooperating with well-known domestic and foreign enterprises, introducing advanced technology, etc., and is committed to building high-grade insulating glass machinery and equipment. . Now, our friendly partners include Northern Glass, Xinfuxing, Yaohua, Dalian Huaying, Beijing Guanhua, Shanghai Haojing, Sichuan Lihehua and other well-known enterprises. Since the establishment of the company, our products have been exported to nearly 30 countries and regions in Europe, America, South America, Middle East, Southeast Asia, India and so on. At the same time, the company cooperates with North China Industrial Group, Shandong University and other well-known domestic research institutions to continuously improve the level of technical research. So far, we have independently produced vertical automatic insulating glass production line with filling gas, vertical insulating glass sealing robot, automatic interval bending machine, automatic dehumidifying filling machine and new automatic butyl rubber extruder, its technology and The quality has reached the highest level of leadership in China.

With the rapid development of the insulating glass industry, Lijiang looks forward to working with you for a win-win situation and a world of innovation.


patent certificate

semi-automatic butyl extruder machiine for insulating glass production line 7

semi-automatic butyl extruder machiine for insulating glass production line 8
semi-automatic butyl extruder machiine for insulating glass production line 9
