Product Details:
|
| Name: | Desiccant Filling Machine | Air Source: | ≥0.65MPa |
|---|---|---|---|
| Power Supply And Power Consumption: | AC220V 50Hz 1.8KW | Molecular Sieve Diameter Needed: | 0.5-0.9mm |
| Dimension: | 1300mm*1100mm*3650mm | Article Aluminum Specifications: | 5.5-24mm |
| High Light: | glass filling machine,desiccant filler |
||
APPLICATION
LJGZ2020 Desiccant Filling Machine
Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer
frames, filling desiccant and sealant. Desiccant Filling Machine control system adopts Germany Siemens,
so the speed of filling is quick and stable operation ensure the valid closure property of sealant.
Desiccant Filling Machine improves quality of insulating glass, it’s a necessary equipment in the
process of insulating glasses.
Main technical parameter
| Name | Brand | Name | Brand |
| PLC | German SIEMENS | Triplet | TAIWAN AIRTAC |
| Low voltage electrical apparatus | German SIEMENS | Solenoid valve | TAIWAN AIRTAC |
| Sensor | Korea AUTONICS | Gas driller | Taiwan BOA |
| Guide | Taiwan TBI | Switch power | Taiwan TEND |
1, Desiccant automatically loading from the Materials bucket.
(When the material was used up the sensor will alarming, desiccant will automatically loading )
2, Auto drilling, filling and sealing function
3,Touching screen interface, simple and visible;Filling time can be adjusted according
to the size of spacer frame in the touch screen
Vision: make glass processing simpler and smarter
Enterprise purpose: seiko manufacturing, quality river
Enterprise values: pioneering and enterprising, mission must be achieved, honest and trustworthy,
optimistic and positive
we exported glass machines and materials to America, South America, Europe, the Middle East, India and so on
nearly 30 countries and regions. We have established a perfect international business relationship
with 10 powerful agents and made an endeavor together to build a famous international brand to the world.
Kation-Tech
Jinan lijiang obtained the national patent
| Filling aluminum frame’s maximum size | 2500mm*2500mm |
| Filling aluminum frame’s minimal size | 300mm*250mm |
| Article aluminum specifications | 5.5-24mm |
| Air source | ≥0.65MPa |
| Power supply and power consumption | AC220V 50Hz 1.8KW |
| Molecular sieve diameter needed | 0.5-0.9mm |
| Dimension | 1300mm*1100mm*3650mm |
FAQ
Q: What's the delivery term?
A:At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working
days after deposit receipt. If you are in urgent need, we can consider making special arrangement for you.
Jinan lijiang, is to ask the most professional manufacturers, do a good job in wooden cases,
and packaging the products, packed in containers, to ensure that the products, without any
damage to the port of destination
