Place of Origin:
CHINA
Brand Name:
LIJIANG
Certification:
CE
Model Number:
LJTB 03
PLC control system, touch screen interface
Frequency control system
Arc frame coating structure
Imported pneumatic and hydraulic supercharging system
Automatic centering and clamping structure
Loading capacity up to 14KG, saving time for feeding glue
Adopt five steps to control convey
Preheating function,glue cylinder limit function,alarm system
Covey and gluing mechanism adopts the latest design
|
Squeeze pressure: |
10-14MPa |
|
Temperature |
110~140℃ |
|
Aluminum spacer width: |
6-24mm |
|
Speed |
0-27m/min |
|
Diameter of butyI cylinder |
190mm |
|
Air pressure |
≥0.8MPa |
|
Total power |
220V/380V 2.5KW 50HZ |
|
Dimension |
3000 x 620x 1102mm(L xWxH) |
|
Weight |
500kg |
