Place of Origin:
China
Brand Name:
LIJIANG
Certification:
CE
Model Number:
LJTB02
Frequency Control Hot Melt Butyl Extruder , Double Glazing Glass Machine
Hot Melt Butyl Extruder features
1. PLC controlling system, touching screen operation;
2. CNC servo motor feeding and bending;
3. World famous brands of key components, ensure stable operation and long service life;
4. Automatic adjustment of processing speed according to aluminum spacer size;
5. Workable for square, retangle and avrious abnormal shaped;
Hot Melt Butyl Extruder Application
Butyl Extruder Machine is used for spreading aluminum spacer frames evenly with hot melt butyl. This equipment use large electrical control panel which makes the operation more easier. The conveyor of aluminum is controlled by frequency converter, and the speed can be adjusted from 0m/min to 47m/min, which has the fastest speed in China. It is very popular with energy-saving. Its squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable. The dispensing cylinder uses vertical rotary support system and it makes the refill of butyl easier. It can prolong the life of squeezing system and set the heating time in 24 hours with electricity and air pressure. The distance of squeezing head can be adjusted automatically according to different aluminum spacer. The machine has reached the worldwide technology with the characteristic of complete function and stable working mode.
on. Successfully displaying IG units products to customers all over the world.
Hot Melt Butyl Extruder Technical Data
| Squeeze pressure | 10-14MPa |
| Temperature | 110-140ºC |
| Aluminum spacer width | 6-24mm |
| Speed | 0-27m/min |
| Diameter of butyl cylinder | 190mm |
| Air supply | Flow:0.4m/min |
| Air pressure | ≥ 0.8MPa |
| Total power | 220V 50HZ 2.5KW |
| Dimension | 3000*620*1102mm |
After sale service
1. 24 hours technical support by phone, email Whatsapp,skype etc.(Choose the most convenient method for you)
2. Engineer is available to your factory for the installation, maintenance and training.
3. Use friendly English software,user manual and detailed videos
4. Warranty for one year,excepting the consumable parts.
By offering this support, we make sure the customer start the business smoothly, to realize win-win cooperation.
