High Power Insulating Glass Filling Machine 300*250 Mm Aluminum Frame Size

High Power Insulating Glass Filling Machine 300*250 Mm Aluminum Frame Size

automatic filling machine

glass filling machine

Place of Origin:

Jinan China

Brand Name:

Lijiang

Certification:

CE

Model Number:

LJGZ2020

Contact Us
Request A Quote
High Power Insulating Glass Filling Machine 300*250 Mm Aluminum Frame Size
Product Details
Color:
Customer's Request
Filling Aluminum Frame's Maximum Size:
2000mm*2000mm
Filling Aluminum Frame's Minimal Size:
300mm*250mm
Article Aluminum Specifications:
5.5-24mm
Air Source:
≥0.65MPa
Weight:
420kg
Meas:
1600*1300*3600mm
Power:
1.8kw
Function:
Filling Desiccant To Aluminium Spacer
Voltage:
Can Be Customized To Local Voltage
Big Frame:
Available
Shaped Frame:
Available
Highlight:

automatic filling machine

,

glass filling machine

Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Seaworthy plastic or plywood available
Delivery Time
30 days
Payment Terms
L/C, T/T
Supply Ability
30 sets/month
RELATED PRODUCTS
Good price PLC Automatic Molecular Sieve Filling Machine Desiccant Filler online

PLC Automatic Molecular Sieve Filling Machine Desiccant Filler

Get Best Price
Good price Automatic Desiccant Filling Machine Molecular Sieve AC220V 50Hz 1.8Kw online

Automatic Desiccant Filling Machine Molecular Sieve AC220V 50Hz 1.8Kw

Get Best Price
Good price Manual Desiccant Filling Machine For IGU Facade Insulating Glass Processing online Video

Manual Desiccant Filling Machine For IGU Facade Insulating Glass Processing

Get Best Price
Good price Molecular Sieve Automatic Desiccant Filler For Glass Processing online

Molecular Sieve Automatic Desiccant Filler For Glass Processing

Get Best Price
CONTACT US
Contact Now
Product Description

Insulating Glass Machine Desiccant Automatic Filling Machine With Adjust Device For Big Frame Can Save Desiccant



Main Features



1.The desiccant automatic filling machine adopts PLC control system with touch screen interface for easy operation.
2.Exclusive and sophisticated feeding device,the storage tank can feed desiccant material as needed.
3. Automatically seal the opening of molecular sieve ​
4. The filling height can be adjusted according to the spacer size.
5. Can filling circular arc frame (optional)

6.It is mainly used to fill both corner-connected spacer frame and spacer frame formed by the automatic spacer bending machine.



Main Technical Parameter



Diameter of the desiccant

0.5-0.9mm
Width of the spacer bar 5.5-24mm
Max processable size 2400*2400mm
Air Pressure 0.6~0.8MPA
Power Supply 220V 50HZ 1KW
Dimension

1300mm*1100mm*3650mm



Factory Display

High Power Insulating Glass Filling Machine 300*250 Mm Aluminum Frame Size 0

High Power Insulating Glass Filling Machine 300*250 Mm Aluminum Frame Size 1



After-Sales Service

1.Training how to install and use the machine.

2.Engineers are available to service machinery in oversea market.
