6A-27A Desiccant Filling Machine

6A-27A Desiccant Filling Machine
6A-27A Desiccant Filling Machine 6A-27A Desiccant Filling Machine 6A-27A Desiccant Filling Machine

Large Image :  6A-27A Desiccant Filling Machine

Product Details:
Place of Origin: CHINA
Brand Name: LIJIANG
Certification: CE
Model Number: LJGZ2020
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Wooden box
Delivery Time: Within 20 days
Payment Terms: L/C, T/T
Supply Ability: 30sets/month

6A-27A Desiccant Filling Machine

Description
Production Name: Desiccant Filling Machine Application: Insulating Glass Making
Aluminum Specifications: 6A-27A Molecular Sieve Diameter Needed: 0.5- 0.9 Mm
Filling Aluminum Frame's Maximum Size: 2000mm*2000mm Filling Aluminum Frame's Minimal Size: 300mm*250mm
Certification: CE After-sales Service Provided: Engineers Available To Service Machinery Overseas
Optional: Big Barrel Dimension: 1300*1100*3600mm
Fuction: Desiccant Filling
High Light:

glass filling machine

,

desiccant filler

,

27A Aluminum Desiccant Filling Machine

Automatic Molecular Sieve Filling Machine Used For filling desiccant into aluminum frame

Product overview​ of Molecular sieve Filling Machine



Automatic molecular sieve Filling Machine can automatically achieve actions of drilling holes automatically in the Aluminum spacer frames, filling desiccant and sealant.



Automatic molecular sieve Filling Machine improves quality of insulating glass, it’s a necessary equipment in the process of insulating glasses.



Automatic molecular sieve Filling Machine control system adopts Germany Siemens, so the speed of filling is quick and stable operation ensure the valid closure property of sealant.



Main feature of desiccant filling machine



• Adopt Siemens PLC control system

• Touch screen interface, easy operation

• The height can be adjusted according to the size of spacer frame

• Automatically loading and replenish desiccant

• Filling time can be adjusted

• Automatically drilling, filling and sealing

• Core parts are imported brands

• Arc frame (optional)

• Fill large particle molecular sieve (Optional)



Main technical parameter of molecular sieve filling machine



Filling aluminum frame’s maximum size 2500mm*2500mm
Filling aluminum frame’s minimal size 300mm*250mm
Article aluminum specifications 5.5-24mm
Air source ≥0.65MPa
Power supply and power consumption AC220V 50Hz 1.8KW
Molecular sieve diameter needed 0.5-0.9mm
Dimension 1300mm*1100mm*3650mm

Details of Molecular Filling Machine



1.Electrical component are all Germany Brand-Siemens.

6A-27A Desiccant Filling Machine 0



2. Machine height can be adjusted according to the size of spacer frame

6A-27A Desiccant Filling Machine 1

3.Protection device for machine head.



6A-27A Desiccant Filling Machine 2



4.Desiccant automatically loading from the Materials bucket.

(When the material was used up the sensor will alarming, desiccant will automatically loading )

6A-27A Desiccant Filling Machine 3



5.Auto drilling, filling and sealing function

6A-27A Desiccant Filling Machine 4



6.All the electrical wires have the ID number,it can match with specification , also it will be very easy for the further communication in the after sales service .

6A-27A Desiccant Filling Machine 5



7.Touching screen interface, simple and visible;Filling time can be adjusted according to the size of spacer frame in the touch screen

6A-27A Desiccant Filling Machine 6



8.All spare parts have ID Number for offering the convenience in after sales service.

6A-27A Desiccant Filling Machine 7




9.Easy and safe for adding glue.

6A-27A Desiccant Filling Machine 8

10. This model has a big barrel to storage desiccant ,no need to put desiccant frequently,increasing efficiency.



6A-27A Desiccant Filling Machine 9

Related products

Desiccant Filling Machine LJGZ 2020A

6A-27A Desiccant Filling Machine 10

Technical data

Max frame size 2000mm*2000nn (2500mm*2500mm)
Min frame size 300mm*250mm
Aluminum specifications 6A - 27A
Air source ≥0.65MPa
Power supply and power consumption AC220V 50Hz 1.5KW
Molecular sieve diameter needed 0.5-0.8mm
Dimension 1650mm*1100mm*3600mm



Main feature

• Germany Siemens PLC control system

• Touching screen interface, simple and visible

• The height can be adjusted according to the size of spacer frame

• Automatically loading and replenish desiccant

• Filling time can be adjusted

• Automatically drilling, filling and sealing

• Core parts are imported brands

• Using big plastic barrel, save feeding time and improve efficiency

• Protection device for machine head

• Adopt vacuum pump loading device ,increase the loading speed

• Arc frame (optional)

• Fill large particle molecular sieve (Optional)

6A-27A Desiccant Filling Machine 116A-27A Desiccant Filling Machine 12

6A-27A Desiccant Filling Machine 13

6A-27A Desiccant Filling Machine 14

6A-27A Desiccant Filling Machine 15

6A-27A Desiccant Filling Machine 16
