Product Details:
Place of Origin: China
Brand Name: LIJIANG
Certification: CE
Model Number: LJTJ2540
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 65000
Packaging Details: container
Delivery Time: 30-40
Supply Ability: 30

Double glass robot sealing machine High quality glass sealing robot Insulating glass sealing machinery

Description
Name: Vertical Insulating Glass Sealing Robot Min. Glass Size: 400*300mm
Working Speed: 5-40m/min Voltage Power: 380V 15kw
Overall Dimension: 11000*2000*3500mm Air Pressure: ≥0.6MPa
High Light:

Automatic Insulating Glass Sealing Robot

,

Double Glass Insulating Glass Sealing Robot

,

Double Glass Sealant Extruder

Double glass sealant extruder insulating glass automatic sealing robot insulating glass sealing robot



Main Features of double glass sealant extruder



Automatically measure glass size, glue depth (30mm)



• Every auto-function is with manual operation

• Can coat double glass

• Shape glass with optional edges, step glass, triple glass (Optional)



• One set of booster pump controls two groups of sealants (Optional)

• Can use silicone, polysulfide and silicone structural sealants

• Glue head is in the front of the machine, which is easy for coating step glass

• Can be connected with insulating glass processing line

• With code scanning function (Optional)



Technical data of insulating glass automatic sealing robot

Max. glass size 2500*4000mm
Min. glass size 400*300mm
Glass thickness 12-50mm
Working speed 5-40m/min
Air pressure ≥0.6MPa
Squeeze pressure 32MPa
Voltage power 380V 15kw
Overall dimension 11000*2000*3500mm



Electrical parameters of glass sealing robot for silicone

NAME ORIGIN BRAND
Servo motor Japan YASKAWA
Servo driver Japan YASKAWA
CPU Japan YASKAWA
Low voltage component Germany SIEMENS
Guideway Taiwan HIWIN
Switching power supply Taiwan MW
Sensor switch Korea AUTONICS
Pneumatic component Japan SMC
Touch screen China GAOSHAN
Servo motor Japan YASKAWA
Servo driver Japan YASKAWA





company profile of insulating glass sealing robot



Jinan Lijiang Automation Equipment Co., Ltd specializes in the R & D and manufacturing of automatic

insulating glass machinery, with a registered capital of 20 million RMB. Domestic friendly partners include

nearly one thousand customers, such as North glass, Xinfuxing, Yaohua, etc. The products have been

exported to Europe, the United States, the Middle East, Southeast Asia, South America,Romania, Bulgaria,

Span and other countries (about 30 countries) of the world. There are about ten agencies, such as North

America, South America, Europe, Southeast Asia, the Middle East, South Korea, etc. At the same time, we

have set up branches in New Delhi, India. At present, the export of products accounts for more than 50% of

the company's total sales.

LIJIANG’ new factory covers an area of 20000 square meters, has more than 100 employees, 6 people with

middle and senior technical titles, 8 full-time technical R & D personnel, 3 production workshops (welding sheet

metal workshop, machining workshop and assembly workshop) and technical R & D department, and has an

independent international trading company (JINAN KATION). The production management and sales system

of the enterprise adopts the advanced ERP and CRM management software in China to build an efficient, accurate,

united and orderly high-end team.
