Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass

Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass
Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass
Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass

Large Image :  Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass

Product Details:
Place of Origin: CHINA
Brand Name: LIJIANG
Certification: CE
Model Number: LJZW2020A
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $35,000 each
Packaging Details: Wooden boxes and containers
Delivery Time: 14 days
Payment Terms: L/C, T/T
Supply Ability: 5 units per month

Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass

Description
Power: 2.5kw Voltage: 220v/380v
Weight: 1200kg Color: Green
Min Glass Size: 250*200mm PLC: Siemens Brand
High Light:

Ig Processing Spacer Bending Machine

,

Insulated Glass Spacer Bending Machine

,

PLC Spacer bar Bending Machine

LIJIANG production line adopts the latest technology, its main purpose is to create high-end quality, to provide customers with the latest production technology, improve production efficiency, save production costs and produce maximum benefits. Now LIJIANG mainly has two kinds of IG line with different two different technologies. One (Picture 1) uses transfer wheels to transport glass, and the other (Picture 2) is a new technology that uses air-floating technology to transport glass. This new technology is to prevent the glass from being contaminated by wheels and leaving traces, so new technology is used to improve the IG production’s high quality.

Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass 0

1.Application

Material rack can be placed at the same time four specifications of aluminum bar, from the outside and inside are respectively 6A,9A,12A,12A above. The innermost group of feed tank is the common feed tank. The plug should be inserted into the middle position, and the plug should be kept level with the aluminum strip or droop slightly, not upwarped, otherwise it will affect the receiving material.
Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass 1

2. Equipment details

Adjust the touch screen to the rectangular working mode, press the right arrow to indicate the transmission of the aluminum bar inside the machine, and press the "refueling" button at the left end of the head with the right hand. After the fixed cylinder of the feed frame is released, the left hand pulls the feed frame to move to the corresponding feed slot, and the right hand releases the button. Manually deliver the aluminium strip to the conveyor belt position.


Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass 2

3. Heavy duty connectors is convenience and safety for installation and debugging Is there any aluminum bar in the induction feeding tank? When there is no aluminum bar and the aluminum bar leaves the induction switch on the left side of the feeding, the aluminum hook wheel picks up the material from the feeding rack.



Max.bending size
2000mm*2000mm
Min.bending size
250mm*200mm
Aluminum spacer width
6A-27A
Dimension error
±0.5mm
Angle error
±1
Air supply
≥0.65Mpa
Total power
AC 220V/380V 50HZ 2.5KW
Dimension
10500mm*2200mm*2600mm



Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass 3Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass 4Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass 5Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass 6Portable Aluminum Spacer Bending Machine For Ig Processing Insulated Glass 7
