Product Details:
|
Certification: | CE & ISO9000 | Dimension(L*W*H): | 8700mm*2000mm*3500mm |
---|---|---|---|
Glass Thickness: | 12-56mm | Max.glass Size: | 2500mm |
Air Pressure: | 0.6-0.8MPa | Plane Angle: | 6°- 9° |
Voltage Power: | 380V 12kw | Max Glass Weight: | 400kg |
Overall Dimension: | 8700mm*2000mm*3500mm | ||
High Light: | Thickness 56mm Insulating Glass Sealing Robot,2500mm Insulating Glass Sealing Robot,Sealing Robot insulating glass machine |
Min & Max glass sizes can be optional
Adopt 8 servo motors
Adopt Japan ANCHUAN servo control system with stable performance
Automatically measure glass size, glue depth and glue speed with linear adjustment
Adopt timing belt to keep smooth convey with accurate position
Spares are produced with high standardization and high precision, ensure the machine can be used with long-term working
The glass corners are full without air bubbles, smooth surface, no need to
Full automatic and high-efficiency machine
New scraper design, especially for making train IG with very even sides and corners, without any bubbles.
Automatically repair glass corners with beautiful surface
Smooth convey without scratch and pollution
Single-function parts are equipped with manual functions, easy adjustment
Shaped IG units (Optional)
Stepped IG units with four sides (Optional)
Double and Triple IG units.
Max.glass size | 2500mm |
Min.glass size | 170mm*400mm (2000mm machine) |
Glass thickness | 12-56mm |
Working speed | 5-40m/min |
Air pressure | 0.6-0.8MPa |
Squeeze pressure | <350kg/m³ |
Plane angle | 6°- 9° |
Max glass weight | 400kg |
Voltage power | 380V 12kw |
Overall dimension | 8700mm*2000mm*3500mm |
