Product Details:
|
| Color: | Customer's Request | Min.bending Size: | 250mm*200mm |
|---|---|---|---|
| Aluminum Spacer Width: | 5.5-24mm | Dimensional Error: | ≤±0.5mm |
| Angle Error: | ≤±1° | Processing Speed: | ≤26s |
| Air Supply: | ≥0.65MPa | Weight: | 1250kg |
| High Light: | spacer bar bending machine,industrial bending machine |
||
Insulating Glass Automatic Spacer Bending Machine For Warm Edge Spacer With Label Printing Function
Main Features
Support continuous bending , it automatically avoid spacer -connection while bending and cutting
Four different spacer size storage units
Can bend aluminum spacer /technoform /Alupro /swisspacer/ stainless steel /thermix (option)
Spacer automatically connecting and cutting , when spacer use out then machine will stop automatically.
Remote control function
Heavy duty connectors ,convenience and safety for installation and debugging
Taiwan Airtac Magnetic valve . German siemens plc control systerm. Japan fuji
USB input function ,it can read the excel data directly
Pause and reset device,convenient for machine malfunction maintained
Spare parts of all machine have ID code ,convenient for after-sale
Spacer inkjet printing ,various color is available(option)
Drill hole for gas filling(option)
Machine clamp device help to bend the bigger spacer(option)
ERP connection function
Manipulator clamping function for support big frame
Label printing function
| Voltage | 380V/50Hz | Feeding speed | 0-90m/min |
| Air pressure | 0.7Mpa | Aluminum bar size | 200*250-2500*2500 |
| Aluminum bar specification | 6-27mm | Date number | (same time set 4 specialization)*(8 size) |
| Bending angle error | ±0.3º | Overall dimension | 10000*2200*2600 |
| Total power | 2.5KW |
| NAME | BRAND | NAME | BRAND |
| PLC | GERMAN SIEMENS | triplet | Taiwan AIRTAC |
| Low voltage electrical apparatus | GERMAN SIEMENS | cylinder | Taiwan AIRTAC |
| Servo motor | JAPAN FUJI | Solenoid valve | Taiwan AIRTAC |
| Servo driver | JAPAN FUJI | Switch power | Taiwan TEND |
| relay | JAPAN OMRON | TOUCH SCREEN | Taiwan WEINVIEW |
| sensor | KOREA AUTONICS | GUIDE | Taiwan TBI |
