Product Details:
|
Name: | Vertical Insulating Glass Production Line LJBZ2535G | Glass Conveyor Speed: | 45m/min |
---|---|---|---|
Washing Brushes: | 3 Pairs Of Soft Brushes With 0.1mm Hair | Air Supply: | Flow: 0.8m/min |
Dimension: | 23500*3500*3700mm | Min. Glass Size: | 280mm*450mm |
High Light: | Hollow Glass Aluminum Spacer Bending Machine,Horizontal Aluminum Spacer Bending Machine,Aluminum Spacer Bending Machine 45m/min |
Automatic aluminum spacer bending machine for horizontal double glazing production line
Main Features of washing machine production line
• The line has 7 parts.
01 transmission part;
02 washing machine;
03 sending part;
04 Inspection and installation section.
05 transmission part;
06 Pressing Section;
07 Discharge section.
• PLC control system, touch screen interface
• Use of Siemens servomotors
• Suitable for the production of double glazing and triple glazing
Optional functions of insulating glass equipment
• Step with optional ledges
• Shaped glass
• Automatic argon gas filling
• Air float technology to transfer glass
To prevent the glass from being contaminated by wheels and leaving traces to improve the IG production’s high quality.
• Pressing and filling 2 pieces of IG units, totally 8 sections
Main Features of glass processing machinery
• Two IGUs can be squeezed at a time to fill with gas, and each IGU can be filled with more than 90% argon gas.
• By pressing two IGUs at a time, you can prevent the shape of the pressed part from collapsing. It takes 27 seconds per 1m x 1m double glazing, which greatly improves work efficiency.
• Patented high speed IG processing line in China in 2019
• Solve the problem of waiting for work on the sealing robot. Installation of two spacer frames for two IGUs by a single craftsman
• Automatically measure glass size and labeling using ERP system (pre-press and post-press labeling can be allowed) (optional)
• Each part is separated from the transfer part to the press part
• Suitable for mass production in factories. super fast
Technical data of glass manufacturing machinery and equipment
Max. glass size | 2500mm*3500mm |
Max glass size for filling gas | 2500mm*3200mm |
Min. glass size | 280mm*450mm |
Glass thickness | 3-15mm |
Insulating glass thickness | 60mm |
Glass washing speed | 2-10m/min |
Glass conveyor speed | 45m/min |
Washing brushes | 3 pairs of soft brushes with 0.1mm hair |
Water supply | Water consumption:0.5t/h conductivity:40μs/cm |
Air supply | Flow: 0.8m/min |
Air pressure | ≥0.8MPa |
Total power | 3P 380V 50HZ 40KW |
Dimension | 23500*3500*3700mm |
Weight | 6500kg |
Electrical parameters of glass manufacturing machinery and equipment
NAME | ORIGIN | BRAND |
PLC | Germany | SIEMENS |
Low voltage electrical appliance | Germany | SIEMENS |
Frequency converter | Germany | SIEMENS |
Servo motor for step glass | Japan | FUJI |
Photoelectric switch | Germany | SICK |
Micro Switch | Taiwan | TEND |
Button and indicator light | France | SCHNEIDER |
Touch screen | Taiwan | WEINVIEW |
Intermediate relay | Japan | OMRON |
Brush motor | China | QINGHUA |
Water pump | China | LINGXIAO |
Guide | Taiwan | HIWIN |
Pneumatic Components | Taiwan | AIRTAC |
IG line without filling gas online |
