Vertical drying washing glass machine For Low E Glass Processing

Large Image : Vertical drying washing glass machine For Low E Glass Processing

Product Details:

Place of Origin:	Jinan
Brand Name:	Lijiang
Certification:	CE
Model Number:	LJQX2535

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	20000usd/set
Packaging Details:	Container
Delivery Time:	20DAYS
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	20SETS/MONTH

Contact Now

Vertical drying washing glass machine For Low E Glass Processing

Description

Voltage:	Requirements	Condition:	New
After-sales Service Provided:	Engineers Available To Service Machinery Overseas	Certification:	CE
Warranty:	1Year	Color:	Blue Or Customize
Name:	Vertical-glass Glazed Washing And Drying Machine	Min. Glass Size:	300x400mm
Usage:	Making Insulating Glass	Glass Thickness:	3~18mm
Max. Glass Size:	3000*2500mm
Highlight:	Low E Drying Washing Glass Machine , Vertical Drying Washing Glass Machine , insulating glass Drying Washing Glass Machine

Glass washing machine technical parameters CP-2500A

5.Cleaning department, wind staff overall lift, the maximum lift: 350mm,easy to clean and maintain； 6.Three pairs of brush(Ø150mm)Stainless steel shaft configuration (low-e glass, ordinary coated glass and sunshine coated glass can be washed without damaging the coated surface)； 7.Two pairs of special stainless steel aluminum alloy air knife configuration, strong wind, good air drying effect, with heating system(with temperature control device, optional opening and closing)； 8.The fan is equipped with air filter in the air inlet chamber, with large air volume and good air drying effect,The whole fan box is installed in the upper part of the workshop, with the air filter screen on the side for easy inspection and cleaning；

Item.	Spec.
Maximum glass width	2500mm (effective maximum: 2650mm)
Minimum glass specification	400mm×400mm (limited to single row on left and right sides)
Glass thickness	3mm-25mm (digital display)
Speed range	glass thickness within 3-25mm Vmax=1-12m/min
Main drive, brush speed regulation method	frequency control
Table height	900±25mm
Total power	42KW(water-bearing wind heating: 15KW)
Water source	self-circulation, tap water (according to civil water standards) and deionized water water supplement (deionized water equipment shall be provided by the buyer)
Power source	380V 50Hz
Dimensions (length × width × height)	approximately 626048003100
Weight	3940kg

Above Information is the Specification from Jinan LIJIANG Glass Technology Standard.
If customers want to change the Specification. Please let us know.

9.Main drive for gear transmission, frequency control, digital display , the rotation of the brush roller in the washing section is driven by independent belts of the upper and lower motors respectively, the frequency conversion adjustment speed is stable, the service life is long, realizes the cleaning high request special glass；

.Mechanical button control, cleaning machine digital display, easy to operate, easy to operate, easy to maintain； .Washing machine water tank outside, convenient water tank cleaning, water change, check, so that the washing machine cleaning effect is cleaner.
