Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line

Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line
Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line

Large Image :  Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line

Product Details:
Place of Origin: China
Brand Name: LIJIANG
Certification: CE
Model Number: LJBZ2535G
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: 90000
Packaging Details: container
Delivery Time: 40-50
Supply Ability: 20set

Automatic Aluminum Spacer Bending Machine For Horizontal Double Glazing Production Line

Description
Name: Vertical Insulating Glass Production Line LJBZ2535G Glass Conveyor Speed: 45m/min
Washing Brushes: 3 Pairs Of Soft Brushes With 0.1mm Hair Air Supply: Flow: 0.8m/min
Dimension: 23500*3500*3700mm Min. Glass Size: 280mm*450mm
High Light:

Aluminum Spacer Bending Machine

,

Double Glazing Spacer Bending Machine

,

IG Glass Spacer Bending Machine

Automatic aluminum spacer bending machine for horizontal double glazing production line

Main Features of  washing machine production line

• This line has 7 sections.
01 Transfer section;
02 washing machine;
03 Emission section;
04 Inspection and installation section.
05 Transfer section;
06 Press and filling section;
07 Discharge section.
• PLC control system, touch screen interface
• Use of Siemens servo motors
• Applicable to the production of double glass and triple glass

Optional functions of  insulating glass equipment

• Step glass with optional edges

• Shaped glass

• Filling argon gas automatically

• Air-floating technology to transfer glass


To prevent the glass from being contaminated by wheels and leaving traces to improve the IG production’s high quality.


• Pressing and filling 2 pieces of IG units, totally 8 sections


Main Features  of  glass processing machinery

• Two IGUs can be pressed at once to fill with gas, and each IGU can be filled with more than 90% argon gas.
• By pressing two IGUs at once, you can prevent the shape of the pressed part from collapsing. It takes 27 seconds per 1m x 1m double glazing, greatly improving work efficiency.
• High-speed IG processing line patented in China in 2019
• Solve the problem of waiting for work on the sealing robot. Installation of two spacer frames for two IGUs by one craftsman
• Automatically measure glass size and labeling using the ERP system (pre-press and post-press labeling can be allowed) (optional)
• Each part is separated from the transfer part to the press part
• Suitable for mass production in factories. Superfast


Technical data  of  glass manufacturing machinery and equipment


Max. glass size2500mm*3500mm
Max glass size for filling gas2500mm*3200mm
Min. glass size280mm*450mm
Glass thickness3-15mm
Insulating glass thickness60mm
Glass washing speed2-10m/min
Glass conveyor speed45m/min
Washing brushes3 pairs of soft brushes with 0.1mm hair
Water supplyWater consumption:0.5t/h conductivity:40μs/cm
Air supplyFlow: 0.8m/min
Air pressure≥0.8MPa
Total power3P 380V 50HZ 40KW
Dimension23500*3500*3700mm
Weight6500kg


Electrical parameters  of  glass manufacturing machinery and equipment



NAMEORIGINBRAND
PLCGermanySIEMENS
Low voltage electrical applianceGermanySIEMENS
Frequency converterGermanySIEMENS
Servo motor for step glassJapanFUJI
Photoelectric switchGermanySICK
Micro SwitchTaiwanTEND
Button and indicator lightFranceSCHNEIDER
Touch screenTaiwanWEINVIEW
Intermediate relayJapanOMRON
Brush motorChinaQINGHUA
Water pumpChinaLINGXIAO
GuideTaiwanHIWIN
Pneumatic ComponentsTaiwanAIRTAC
IG line without filling gas online
