Manual Argon Gas Filling Machine In Double Glazing Hollow Glaszing Processing

Large Image : Manual Argon Gas Filling Machine In Double Glazing Hollow Glaszing Processing

Product Details:

Place of Origin:	Jinan City, Shandong Province, China
Brand Name:	Jinan Lijiang Glass Machinery
Certification:	CE & ISO9000

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiated Price
Packaging Details:	Wooden Cases Package
Delivery Time:	5-8 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	15 sets per month

Contact Now

Manual Argon Gas Filling Machine In Double Glazing Hollow Glaszing Processing

Description

Name:	Argon Gas Filling Equipment	Advantage:	One Time For Four Pieces
PLC:	Siemens Brand	Inflation Pressure:	0.4Mpa
Inflation Flow:	60L/min	Inflation Adjustment:	0-80L/min
Gas Source Purity:	99.99 (argon)	Using Environment:	0-40℃
Highlight:	Manual Argon Gas Filling Machine , Double Glazing Argon Gas Filling Machine , Hollow Glaszing Argon Gas Filling Machine

Manual Argon Gas Filling Equipment used for Double Glazing Insulated Glass Processing

Argon gas filling machine LJCJ03


As we all know, filling the insulating glass with argon (inert gas) is very helpful to improve the insulation performance of the insulating glass and the sound insulation performance of the insulating glass. Filling with high-standard dry inert gas can prevent the internal oxidation of the insulating glass, especially to prevent the oxidation of low-E glass, clean the internal and external pressure imbalance of the insulating glass, and prevent the large pieces of insulating glass from sticking together.Main Function 1.Four pieces of IGU can be gas-filled at the same time within the 20s (1m*1m glass). 2.Pressure alarm device: when the gas filling is up to adjusted value, it will alarm and stop automatically. 3.The filling process can display on the touch screen. 4.Gas content setting: the customer can set the argon content in the IGUs according to his own needs. 5.The whole filling process and argon gas content can be displayed on the screen, and the argon gas content can be observed in real-time.

6.High effectively, allowing for four IG glass. 7.When the gas is full, it will alarm and stop automatically.

Main Technical Parameter

Item.	Spec.
Power supply	220V 50Hz
Total power	0.1kw
Dimension	700mm420mm700mm
Inflation pressure	0.4Mpa
Inflation flow	60L/min
Inflation adjustment range	0-80L/min
Gas source purity	99.99 (argon)
Argon gas source	Pressure 0.1Pa, the flow rate 0.01L / min
Using environment	0-40℃
No condensation, no water intrusion into the operation panel and electric control box.
Total weight	30kgs

Advantages & Features

Main Feature

Inflate 4 pieces of insulating glass at a time2. Automatically display inflation status
An imported gas analyzer is used for gas source gas analysis with an accuracy of 99.99%.
Four-way inflation can complete the inflation of four insulating glass
The gas sensor imported from Japan can individually detect the internal gas of the hollow glass after each line is inflated
Reasonable mechanical design makes inflation more convenient
All sophisticated gas connection devices are imported from South Korea
The inflatable state light indication is obvious
The detection interface is designed ingeniously and fully detects the gas inside the hollow glass
The various indications of the equipment accurately guide the operator to use it correctly
This equipment is used to fill the interior of insulating glass with inert gas to improve the performance of insulating glass, such as heat insulation, sealing, sound insulation, and energy-saving. The gas purity analyzer imported from the United States and the gas sensor imported from Japan ensure the stability of the inflator. The humanistic appearance design makes the equipment beautiful and easy to operate.
