Product Details:
|
Min.glass Size: | 280*450mm | Glass Thickness: | 3-15mm |
---|---|---|---|
Insulating Glass Thickness: | 50mm(special Made For 60mm) | Glass Washing Speed: | Summer 8-10m/min Winter 6-7m/min |
High Light: | Intelligent Insulating Glass Processing Machin,Various Departments Insulating Glass Processing Machin,Intelligent glass production machinery |
1, To Avoide the low-e Glass put inverse side and Leave wheel marks or scratch low-e Coating We use coating inspection -metal film conductive (other company use Photoelectric detection, hard to recognize for higher transparent)
2, three pairs soft brushes can wash low-e glass and normal glass , the diameter is less than 0.1mm.
3, Materials are stainless steel.
4, Air knife is float design , it always keep the right and suitable distance 3mm between the glass surface and air knife (Same like LISEC structure ) check the following picture. (3mm is the best drying distance)
5, The front and back side squeeze wheel are all actively moved and convey. No mater the glass size is big /small or thickness different(8mm) , it all guarantee the glass pass through smoothly.(Same like LISEC)
6, There have stress after welding in the Pressing frame ,
so the out-of -shape problems is inescapable after using some time
(machine can not press DGU properly evenly and tightly )
that is not good for IGU quality, any glass project can not accept these products
7,For this uneven inescapable issue, here are our solution :
a. we all do the aging treatment , it’s the stress-remove by vibration failure device.
b. The important is We design the 74 points on the backbord, if there have any out-of shape problems we can adjust easily at any time. ( same like Bystronic structure )
8, Input the argon gas concentration into touch screen according to customer required
9, Display Function : touch screen will display whole argon gas filling processing , you will know very clear how much already argon gas filed inside
We are the first and the only one company who can show the argon percentage on the touch screen on line,its very useful for customer,When it reach the data customer set ,It will alarm and stop automatically
10, GAS filling from bottom and it was designed separately for saving gas .
A: The pressing part was devided into 4 part , (per 800mm), when the small size glass(less than 800mm) pass through the pressing and gas filling section, ,only one part work.if more than 800mm but less than 1600mm,it will two parts work, no need the whole press and gas filling section work. it can save the argon gas.
Technical data
Components | Brand | Remark |
Servo motor | Germany Simens | For stepped glass |
Servo driver | Germany Simens | For stepped glass |
Servo motor | Germany Simens | For transfer |
Servo motor | Germany Simens | For press |
PLC | Germany Simens | |
Low voltage component | Germany Simens | |
Frequency converter | Germany Simens | |
Switching power supply | Taiwan MW | |
Optoelectronic switch | Korea Autonics | |
Pneumatic component | Taiwan Airtac | |
Pneumatic component | Taiwan Airtac | |
Touch screen | Taiwan Wenview | |
Travel switch | Taiwan (TEND) | |
Relay | Japan Omron | |
Button and indicator light | French Schneider |
Max.glass size | Normal glass | 2500*3500mm |
Glass with argon gas | 2500*3200mm | |
Min.glass size | 280*450mm | |
Glass thickness | 3-15mm | |
Insulating glass thickness | 50mm(special made for 60mm) | |
Glass washing speed | Summer 8-10m/min winter 6-7m/min | |
Glass conveyor speed: | 45m/min | |
Washing brushes | 3 pairs | |
Water supply: | Water consumption:0.5t/h conductivity:≤50μs/cm6-7 | |
Air supply | Flow: 0.8m/min | |
Air pressure | ≥0.8MPa | |
Total power | 3P380V 50HZ 34KW | |
Dimension | 23500*3500*3700mm |
