Product Details:
|
| Name:: | Automatic Sealing Robot | Model:: | LJTJ2540 |
|---|---|---|---|
| Power:: | 15KW | Voltage:: | 380V |
| Weight:: | 5000KG | Overall Dismension:: | 8700*2500*3500 MM |
| Squeeze Pressure:: | <35MPa | Air Pressure:: | 0.6-0.8MPa |
| Working Speed:: | 5-40m/min | Glass Thickness:: | 12-56 Mm |
| Max.glass Size:: | 2500*4000 MM | Min.glass Size:: | 400*300 MM |
| High Light: | Double Glass Sealant Extruder,2500×4000MM Sealant Extruder,2500×4000MM silicone extruder machine |
||
Double glass sealant extruder insulating glass automatic sealing robot insulating glass sealing robot
Sealing robot insulating glass double glazed sealing machine
silicone extruder machine,sealant dispensing machine,silicone sealant,sealant dispensing equipment,small extruder machine,insulating glass sealant,extruder machine
l Full automatic and high-efficiency machine
l New scraper design, especially for making train IG with very even sides and corners, without any bubbles.
l Min & Max glass sizes can be optional
l Adopt 8 servo motors
l Adopt Japan ANCHUAN servo control system with stable performance
l Automatically measure glass size, glue depth and glue speed with linear adjustment
Main electrical components
The main electrical components are adopted Siemens, SMC and so on famous spares to maintain more stable performance.
Technical parameter
| Max.glass size | 2500*4000mm |
| Min.glass size | 400*300mm |
| Glass thickness | 12-56mm |
| Working speed | 5-40m/min |
| Air pressure | 0.6-0.8MPa |
| Squeeze pressure | 32MPa |
| Voltage power | 380V 12kw |
| Overall dimension | 8700*2500*3500mm |
