Product Details:
|
| Production Name: | Automatic Sealing Robot | Max Glass Size: | 2000*2500 |
|---|---|---|---|
| Pressing Twice: | 2000*3000 | Glass Thickness: | 60 Mm |
| Glass Type: | Double/triple/step Glass | Warranty: | 1 Year |
| High Light: | 2000*2500 Silicone Sealant Coating Machine,Insulating Glass Silicone Sealant Coating Machine,2000*2500 Insulating Glass Sealing Robot |
||
Automatic sealing robot - 2000 (Height) *2500
Vertical Insulating Glass Sealing Robot silicone extruder machine
Application of silicone extruder machine
Adopt 8 servo motors
l Adopt Japan servo control system with stable performance
l Automatically measure glass size, glue depth and glue speed with linear adjustment
l Adopt timing belt to keep smooth convey with accurate position
l Spares are produced with high standardization and high precision, ensure the machine can be used with long-term working
l The glass corners are full without air bubbles, smooth surface, no need to
l Full automatic and high-efficiency machine
l New scraper design, especially for making train IG with very even sides and corners, without any bubbles.
l Automatically repair glass corners with beautiful surface
l Smooth convey without scratch and pollution
l Single-function parts are equipped with manual functions, easy adjustment
Detail Images silicone extruder machine
Ø One Set of Pump A & Pump B
Equipped with single A component and single B component. Glue A and B automatic mixing, automatic ratio.
Ø Back Glue Device
When the pressure increasing, more Glue B will flow back automatically, saving materials.
Ø Dyad Body Device
The dyad body device has two functions. The left one is used for filtering impurities and moisture when filling gas into , then the right one plays the role of lubrication.
Ø The Device of Sealing Part
Adopt Japan YASKAWA servo motor to control the sealing part with 360°rotating. Setting scraper blade to scrape out extra glue and no need to repair glass corners by second time.
Ø Timing belt
The time belt device ensure that glass can be smooth transmission and positioned accurately.
Automatically position the glass and sensor glue deep, the coating speed can be adjustable online.
Ø Storage Function
It can store three pieces of insulating glasses when glass sizes are less than 1.8m.
Ø Equipped with MANUAL DEVICE
Every separate part is equipped with manual operation, be easy to adjust in case.
Ø Eight Servos
The robot uses eight YASKAWA servos, four of them control transmission parts, in the another four servos, they control sucker, lifting, driving and revering mechanism and rotating.
Ø Main electrical components
The main electrical components are adopted Siemens, SMC and so on famous spares to maintain more stable performance.
² Technical data silicone extruder machine
| Max.glass size | 2500mm |
| Min.glass size | 170mm*400mm (2000mm machine) |
| Glass thickness | 12-56mm |
| Working speed | 5-40m/min |
| Air pressure | 0.6-0.8MPa |
| Squeeze pressure | <350kg/m³ |
| Plane angle | 6°- 9° |
| Max glass weight | 400kg |
| Voltage power | 380V 12kw |
| Overall dimension | 8700mm*2000mm*3500mm |
Main components list silicone extruder machine
| Name | Brand |
| Switch | SIEMENS |
| Servo motor | Japan YASKAWA |
| I/O model | Japan MSYSTEM |
| Lower voltage component | Siemens |
| CPU | Japan YASKAWA |
| Frequency converter | Japan OMRON |
| Switching power supply | Taiwan MW |
| Pneumatic component | Japan SMC |
| PLC | Siemens |
| Guideway | Siemens |
