Low E Glass Vertical 3000r/min Glass Edge Polishing Machine for Insulated Glass Belt Grinding

Large Image : Low E Glass Vertical 3000r/min Glass Edge Polishing Machine for Insulated Glass Belt Grinding

Product Details:

Place of Origin:	Jinan City, Shandong Province, China
Brand Name:	Jinan Lijiang Glass Machinery
Certification:	CE & ISO9000
Model Number:	LJCM2545 Smart Vertical Edge Deleting Machine

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Discussible
Packaging Details:	Wooden Cases Package
Delivery Time:	5-8 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	100 sets per month

Contact Now

Low E Glass Vertical 3000r/min Glass Edge Polishing Machine for Insulated Glass Belt Grinding

Description

Machine Type:	Glass Drilling Machine	Dimension(LWH):	970025003400mm
Certification:	CE & ISO9000	Glass Thickness:	1-40mm
Total Air Consumption:	100L/ Min	Total Power:	3P 380V 50Hz 3.35KW
Dimensions:	970025003400mm	Air Pressure:	≥0.8MPa
Grinding Wheel Speed:	0~3000r/min
Highlight:	3000r/min Glass Edge Grinding Machine , Low E Glass Edge Grinding Machine , 3000r/min glass edge grinder

High speed Low-E Glass Film Deleting Machine for Coated Glass Reflective Glass Remover Manufacturer Hot Sale on March EXPO
Products Description

Smart Vertical Edge Deleting Machine LJDM2545
LJDM2545 smart vertical edge deleting machine is used to delete the edge film of the Low-e glass. The glass edge deleting machine adopts imported servo control system, positioning accurately with smooth operation. High quality grinding wheels are durable, can produce neat and beautiful grinding crack. The distance can be set among 10 ~ 150 mm arbitrarily.

Advantages & Features

Benefits & Advantages

•Japan Yaskawa servo system control, full automatic and high-efficiency sealing machine •4 sections, can storage glass •Adopt timing belt, smooth transfer and accurate position •Automatically repair glass corners with scraper and roller •Automatically measure glass size, glue depth (30mm) •Every auto-function is with manual operation •Can coat double glass •Shape glass with optional edges, step glass, triple glass (Optional) •One set of booster pump controls two groups of sealants (Optional) •Can use silicone, polysulfide and silicone structural sealants •Glue head is in the front of the machine, which is easy for coating step glass •Can be connected with insulating glass processing line •With code scanning function (Optional)
 The Smooth Glue Surface
After applying glue, It will ensure that the corners of the glass are full, without bubbles and other impurities, and the glue surface is so smooth.
 The High-precision Servo Control System
It adopts Japanese Yaskawa servo control system with clear wiring layout to ensure stable overall performance of the equipment.
 The Glass Coating
Automatically measure glass size, glue depth and glue speed through linear adjustment to ensure the stability of insulating glass coating quality.
 Glue Pump A and Glue Pump B
Equipped with a single A component and a single B component, mixed and glued. When applying glue, glue pump A and glue pump B are automatically mixed to realize automatic proportioning.

Above information is the Benefits&Advantages from Jinan LIJIANG Glass.
If customers want to know more advantages, please contact us directly.
Main Technical Parameter

			Item.

			Spec.

			Max. glass processing size

			2500*4500mm

			Min. glass processing size

			400*280mm

			Glass thickness

			3-15mm

			Diameter of grinding wheel

			200mm

			Conveyor height

			500mm

			Edge deleting width

			10-50mm

			Transmission speed

			29m/min

			Edge deleting speed

			2-29m/min

			Abrasive wheel width

			10/12/15mm

			Grinding wheel speed

			0~3000r/min

			Total air consumption

			100L/ min

			Air pressure

			≥0.8MPa

			Total power

			3P 380V 50Hz 3.35KW

			Dimension

			9700×2500×3400mm

			Total weight

			3700KG

Above information is the Specification from Jinan LIJIANG Glass Tech. Standards.
If customers want to know more details, please contact us directly.
