Product Details:
|
Name: | Vertical Insulating Glass Production Line | Max. Glass Size: | 2500mm*3500mm |
---|---|---|---|
Min. Glass Size: | 280mm*400mm | Insulating Glass Thickness: | 50mm / 60mm |
Glass Washing Speed: | 2-10m/min | Glass Conveyor Speed: | 45m/min |
High Light: | insulating glass line,glass processing machines |
Main feature:
• Extra long insulated glass can be compressed twice
• The machine adopts servo torque to push the glass
• Adjustable screwed push plate to ensure a long lasting precision tablet
• Equipped with precisely adjustable front platen mechanism
• The system can diagnose fault information
• Push plate can be opened up to 400mm width for easy maintenance
• Applicable for manufacturing 4 side step IG, triple IG and shaping IG
Filling argon gas automatically
• Automatically fills the press plate with argon gas at the correct gas concentration
• 450 mm (length) and 280 mm (height) expansion is required in front of rectangular size when filling molded IG
• No need to drill holes in the spacer frame
• Argon is the standard gas
• Fast reaction sensor for permanent control of the gas filling process
• Automatically set gas data and display data on screen
Features
• Two IGUs can be pushed at once for gas filling, each IGU can be filled with argon
90% or more gas.
• By pressing two IGUs, you can better prevent the pressed parts from losing their shape.
At one time.
• High speed IG processing line
• Solves the problem of waiting for the sealing robot to work. Work efficiency is greatly improved.
• One worker installs two spacer frames on two IGUs.
• Automatically measure glass size and labeling (labeling is
After pressing) on the ERP system.
• There are separate parts from the transfer part to the press part.
• Best for mass production in factories, super fast.
Max. glass size | 2500mm*3500mm |
Min. glass size | 280mm*400mm |
Glass thickness | 3-15mm / 19mm |
Insulating glass thickness | 50mm / 60mm |
Glass washing speed | 2-10m/min |
Glass conveyor speed | 45m/min |
Washing brushes | 3 pairs |
Water supply | Water consumption:0.5t/h conductivity:40μs/cm |
Air supply | Flow: 0.8m/min |
Air pressure | ≥0.8MPa |
Total power | 3P 380V 50HZ 40KW |
Dimension | 23500*3500*3700mm |
Weight | 6500kg |
Electrical parameters
NAME | ORIGIN | BRAND |
PLC | Germany | SIEMENS |
Low voltage electrical appliance | Germany | SIEMENS |
Frequency converter | Germany | SIEMENS |
Servo motor | Japan | FUJI |
Photoelectric switch | Germany | SICK |
Micro Switch | Taiwan | TEND |
Button and indicator light | France | SCHNEIDER |
Touch screen | Taiwan | WEINVIEW |
Intermediate relay | Japan | OMRON |
Brush motor | China | QINGHUA |
Water pump | China | LINGXIAO |
Guide | Taiwan | HIWIN |
Pneumatic Components | Taiwan | AIRTAC |
IG line without filling gas online |
Jinan Lijiang Automation Equipment Co., Ltd. is located in the beautiful spring
city------Jinan. It is an enterprise which integrated glass processing equipment research and development,sales and service into a whole. As it is close to Beijing-Shanghai high-speed rail, the transportation is veryconvenient.
The company is committed to building high-end insulating glass machinery and equipment by learning from famous experts, establishing the research and development centers, cooperating with domestic and foreignwell-known enterprises, importing advanced technology and so on. Now, our friendly partners include North Glass, Xin Fuxing, Yaohua, Dalian Huaying, Beijing Guanhua, Shanghai Hao Jing, Sichuan Li Hehua and other well-known enterprises. Since the establishment of the company, our products have been exported to Europe,America, South America, the Middle East, Southeast Asia, India, nearly 30 countries and regions. At the same time, our company worked with the well-known domestic research institutes, such as the North China Industrial
Group, Shandong University and others, to constantly improve the level of technical research. So far, we have independently produced the vertical automatic IG production line with filling gas on line, the vertical IG sealing robot, the automatic spacer bending machine, the automatic desiccant filling machine and the new fully automatic butyl extruder machine, its technology and quality have reached the highest leading level in China.
With the rapid development of insulating glass industry, LIJIANG is looking forward to working with you for win-win situation and jointly creating a new world.
