LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line

Large Image : LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line

Product Details:

Place of Origin:	China
Brand Name:	Lijiang
Certification:	CE
Model Number:	LJBZ2535

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	Negotiable,
Packaging Details:	wooden case or container
Delivery Time:	60days
Payment Terms:	L/C, T/T
Supply Ability:	10set/month

Contact Now

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line

Description

Name:

Vertical Automatic Insulating Glass Production Line

Advantage:

Gas Filling On Line

PLC:

Siemens

Highlight:

glass processing machines

double glazing production

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line 0

LIJIANG GLASS-FOR WORLD GLASS MANUFACTURE SERVICE

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line 1

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line 2

LJBZ2535 Vertical Automatic Insulating glass

production line with gas filling on line

APPLICATION
As the most important process of insulating glass production, we are especially professional in glass cleaning, transmitting pressing and gas filling(optional).The production line can do double glass,triple glass and stepped glass.

LJBZ2535 Vertical Automatic Insulating glass

production line with gas filling on line

include 7 parts: (from right to left)

1,Loading section(with low-e checking)

2,washing and drying section(can washing low-e glass)

3,conveyor section

4,checking and assembly section

5, conveyor , measure and sensor section

6,press part with gas filling

7,unloading section

• Adopt SIEMENS control system, keep stable performance • PLC control system, touch screen interface

• Automatically adjust the depth of glue with digital display

• Using servo to control system, modular function, superposition function

• Applicable to produce stepped IG, triple IG and shaped IG • Two pieces of IGU can be made and filled with argon gas in one time (Optional)

• Min & Max glass sizes can be optional

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line 3

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line 4

LJBZ2535 Vertical Automatic Insulating glass

production line with gas filling on line

Main technical parameters

Max.glass size	25003500mm(LJBZ2535) Gas filling line 2535G:25003200mm
Min.glass size	280*450mm
Glass thickness	3-12mm
Insulating glass thickness	60mm
Glass washing speed	2-10m/min
Glass conveyor speed:	48m/min
Washing brushes	3 pairs
Water supply:	Water consumption:0.5t/h conductivity:≤50μs/cm
Air supply	Flow: 0.8m/min
Air pressure	≥0.8MPa
Total power	3P380V 50HZ 34KW
Dimension	2350035003700mm

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line 5

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line 6

Parts list

Components	Brand	Remark
Servo motor	GERMAN SIEMENS	For stepped glass
Servo driver	GERMAN SIEMENS	For stepped glass
Servo motor	GERMAN SIEMENS	For transfer
Servo motor	GERMAN SIEMENS	For press
PLC	GERMAN SIEMENS
Low voltage component	GERMAN SIEMENS
Frequency converter	GERMAN SIEMENS
Switching power supply	Taiwan MW
Optoelectronic switch	Korea Autonics
Pneumatic component	Taiwan Airtac
Pneumatic component	Japan SMC
Touch screen	Taiwan Wenview
Travel switch	Taiwan Tiande

Option function of LJBZ2535 Vertical Automatic Insulating glass

production line:Gas filling on line

Gas filling online, we can input the suitable gas proportion value on the touch screen , during the gas filling process, the touch screen can show us the whole gas filing process visually . (You can see the video that I have sent you before.)We are the first and the only one company who can show the argon percentage on the touch screen on line,its very useful for customer,When argon gas filling,it will show the whole process on the screen. When it reach the data customer set ,It will alarm and stop. So it can save the argon gas. And save the time.

LJBZ2535 Vertical Automatic Insulating glass production line with gas filling on line 8
