6 Brushes 16 a Vertical Washing And Drying Machine

6 Brushes 16 a Vertical Washing And Drying Machine
6 Brushes 16 a Vertical Washing And Drying Machine 6 Brushes 16 a Vertical Washing And Drying Machine 6 Brushes 16 a Vertical Washing And Drying Machine

Large Image :  6 Brushes 16 a Vertical Washing And Drying Machine

Product Details:
Place of Origin: China
Brand Name: Lijiang
Certification: CE
Model Number: LJLBQJ2500
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable,
Packaging Details: wooden case or container
Delivery Time: 20days
Payment Terms: T/T, L/C
Supply Ability: 10set/month

6 Brushes 16 a Vertical Washing And Drying Machine

Description
Name: Vertical Washing And Drying Machine Material: Stailess Stell Touching Water Part
Advantage: Brush For Low-e Type: Vertical
High Light:

double glazing production

,

insulating glass line

Vertical Washing And Drying Machine Easy Opration Glass Cleaning Use



6 Brushes 16 a Vertical Washing And Drying Machine 0

Glass Washing Machine LJLBQJ2500




6 Brushes 16 a Vertical Washing And Drying Machine 16 Brushes 16 a Vertical Washing And Drying Machine 2

Structural characteristics:

* The rest of the sheet metal parts are sprayed with advanced mechanical paint or powder;
* Aluminum alloy assembled structure, no scrap concept, permanent use,high efficiency, energy saving 70% efficiency;
* The rubber roller is made of vulcanized rubber with stainless steel shaft;
* The washing part in contact with water is made of stainless steel;
* Cleaning department, wind staff overall lift, the maximum lift: 350mm,easy to clean and maintain;
* Three pairs of brush(Ø150mm)Stainless steel shaft configuration (low-e glass, ordinary coated glass and sunshine coated glass can be washed without damaging the coated surface);
* Two pairs of special stainless steel aluminum alloy air knife configuration, strong wind, good air drying effect, with heating system(with temperature control device, optional opening and closing);
* The fan is equipped with air filter in the air inlet chamber, with large air volume and good air drying effect,The whole fan box is installed in the upper part of the workshop, with the air filter screen on the side for easy inspection and cleaning;
* Main drive for gear transmission, frequency control, digital display , the rotation of the brush roller in the washing section is driven by independent belts of the upper and lower motors respectively, the frequency conversion adjustment speed is stable,the service life is long, realizes the cleaning high request special glass;
* Mechanical button control, cleaning machine digital display, easy to operate, easy to operate, easy to maintain;
* Washing machine water tank outside, convenient water tank cleaning, water change, check, so that the washing machine cleaning effect is cleaner.
* Optional with PLC control, touch screen display.It is convenient for workers to operate and maintain, and can be connected to all manufacturers of edge grinding machines without gap.(purchase separately if necessary)
6 Brushes 16 a Vertical Washing And Drying Machine 36 Brushes 16 a Vertical Washing And Drying Machine 4

►The washing machine uses six soft (Low-e) brushes with the 01mm diameter only.

It has 6 brushes which are all soft brush, can wash low-e glass, flat glass, tempered glass and so on. It has a diameter of less than 0.1mm bristles, never damage glass, especially for low-e glass.

6 Brushes 16 a Vertical Washing And Drying Machine 5

The noise can be controlled below 90 decibels by using nylon gear and sponges.

6 Brushes 16 a Vertical Washing And Drying Machine 66 Brushes 16 a Vertical Washing And Drying Machine 7

Using Europe's advanced anti-noise system to create a good working environment for employees.The noise can be controlled below 90 decibels by using nylon gear and sponges.

6 Brushes 16 a Vertical Washing And Drying Machine 8

Warer Treatment Description►►►

1. The quartz sand filter

Accumulative work is up to 8 ~ 20 hours, back flush for 20 minutes.

Accumulative work is up to 1.5 -2 hours, replace the quartz sand filter material.

2. The activated carbon adsorption filter:

When exports residual chlorine content > 0.1 mg/L, should replace the activated carbon filter material, normally when the cumulative work is up to 1 year, replace the activated carbon filter material.

3. The water softener:

Replace the softening resin for 1 year work

4. The security filter

Generally, cumulative work for three months ,a fine filter should be replaced. When the fine filter pressure is less than 0.04 Mpa and water shortage indicator light is on,a fine filter should be replaced,too.

5. Inverse osmosis filter

After 6 months of work, application drug RO membrane should be clean.

After 1-1.5 years accumulated work,we should replace the RO membrane.

Main parameters

Power 380 v/50 hz
Rated current 16 a
The rated working pressure 1.0 ~ 1.2 Mpa
Raw water pressure and flow rate ≥0.15 Mpa ≥1.5 T/H
Water rate 500 l/H 25 ℃ under the pressure of 1.2 Mpa
Booster pump 0.55 KW CHL2-40
Multistage pump 1.5 KW CDL2-13


6 Brushes 16 a Vertical Washing And Drying Machine 9

6 Brushes 16 a Vertical Washing And Drying Machine 10

6 Brushes 16 a Vertical Washing And Drying Machine 11

6 Brushes 16 a Vertical Washing And Drying Machine 126 Brushes 16 a Vertical Washing And Drying Machine 13
