Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine
Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine

Large Image :  Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine

Product Details:
Place of Origin: China
Brand Name: Lijiang
Certification: CE
Model Number: LJJT01
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable,
Packaging Details: wooden case or container
Delivery Time: 20days
Payment Terms: T/T, L/C
Supply Ability: 10set/month

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine

Description
Name: Butyl Extruder Max Working Speeding: 47m/min
Max Sapcer Width: Can Be Request Type: Insulating Glass Production Line
High Light:

glass processing machines

,

double glazing production

Super-fast Speed Butyl Extruder machine for Insulating Glass



      LIJIANG GLASS-FOR WORLD PROCESSING GLASS MANUFACTURE SERVICE



Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 0

Express Speed Butyl Extruder machine for Insulating Glass with New Technolgy LJJT01

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 1

The type of LJTB01 butyl extruder machine is used for spreading aluminum spacer frames evenly with hot melt butyl. This equipment use large electrical control panel which makes the operation more easier. The conveyor of aluminum is controlled by frequency converter, and the speed can be adjusted from 0m/min to 47m/min, which has the fastest speed in China. It is very popular with energy-saving. Its squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable. The dispensing cylinder uses vertical rotary support system and it makes the refill of butyl easier. It can prolong the life of squeezing system and set the heating time in 24 hours with electricity and air pressure. The distance of squeezing head can be adjusted automatically according to different aluminum spacer. The machine has reached the worldwide technology with the characteristic of complete function and stable working mode.

Main feature

· Touch-screen operation, which makes the machine simple and practical

· Stable temperature and it is convenient to adjust the sealing material automatically

· According to the changed coating speed

· Recognize the aluminum spacer size automatically



Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 2

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 3

♦♦♦Easy to change butyl system

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 4

♦♦♦Automatic spacer width control



Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 5Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 6

♦♦♦Shape spacer model

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 7

♦♦♦Germany Siemen system



Squeeze pressure 10-18MPa
Temperature 110~140℃
Aluminum spacer width 4-30mm
Speed 0-47m/min
Diameter of butyl cylinder 200mm
Air supply 0.4m³/min
Air pressure ≥0.6MPa
Total power 380V, 5KW, 50HZ
Dimension 2600×680×1100mm(L×W×H)
Weight 650kg





Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 8

Automatic Butyl Robot

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 9

Main feature

· PLC control system, touch screen interface.

· Frequency control system

· Abroad technology, pneumatic and hydraulic supercharging system.

· Automatic centering and clamping structure.

· Separate extruder head structure.

· Automatic butyl volume display function.

· Circular arc butyl sealing structure.

· Extruder head height adjustment structure

· Preheating function Butyl cylinder swing mechanism

· Important control parts adopt imported brand.



technical parameter

Squeeze pressure 10-14MPa
Temperature 110-140ºC
Aluminum spacer width 6-24mm
Speed 0-27m/min
Diameter of butyl cylinder 190mm
Air supply Flow:0.4m/min
Air pressure ≥ 0.8MPa
Total power 220V 50HZ 2.5KW
Dimension 3000*620*1102mm



Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 10
Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 11

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 12

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 13

Super Fast Speed Insulating Glass Production Line Butyl Extruder Machine 14
