High Speed Insulating Glass Production Line Butyl Extruder Machine

High Speed Insulating Glass Production Line Butyl Extruder Machine
High Speed Insulating Glass Production Line Butyl Extruder Machine High Speed Insulating Glass Production Line Butyl Extruder Machine High Speed Insulating Glass Production Line Butyl Extruder Machine

Large Image :  High Speed Insulating Glass Production Line Butyl Extruder Machine

Product Details:
Place of Origin: China
Brand Name: Lijiang
Certification: CE
Model Number: LJJT01
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable,
Packaging Details: wooden case or container
Delivery Time: 10days
Payment Terms: L/C, T/T
Supply Ability: 20set/month

High Speed Insulating Glass Production Line Butyl Extruder Machine

Description
Name: High Speed Butyl Extruder Machine For Insulating Glass Processing Equipment Working Speeding: 5-47m/min
Aluminum Spaer Width: 6-27mm Type: Insulating Glass Production Line
High Light:

glass processing machines

,

double glazing production

High Speed Butyl Extruder machine for Insulating Glass with New Technolgy





High Speed Insulating Glass Production Line Butyl Extruder Machine 0

Butyl Extruder Machine LJTB 01

High Speed Insulating Glass Production Line Butyl Extruder Machine 1



Butyl Extruder Machine LJTB 01

Application

The type of LJTB01 butyl extruder machine is used for spreading aluminum spacer frames evenly with hot melt butyl. This equipment use large electrical control panel which makes the operation more easier. The conveyor of aluminum is controlled by frequency converter, and the speed can be adjusted from 0m/min to 47m/min, which has the fastest speed in China. It is very popular with energy-saving. Its squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable. The dispensing cylinder uses vertical rotary support system and it makes the refill of butyl easier. It can prolong the life of squeezing system and set the heating time in 24 hours with electricity and air pressure. The distance of squeezing head can be adjusted automatically according to different aluminum spacer. The machine has reached the worldwide technology with the characteristic of complete function and stable working mode.

Technical Data

Squeeze pressure 10-18MPa
Temperature 110~140℃
Aluminum spacer width 4-30mm
Speed 0-47m/min
Diameter of butyl cylinder 200mm
Air supply 0.4m³/min
Air pressure ≥0.6MPa
Total power 380V, 5KW, 50HZ
Dimension 2600×680×1100mm(L×W×H)
Weight 650kg





Main components

Name Brand Original
PLC KINCO China
Valve HAWE German
Low voltage electrical apparatus SIEMENS German
Hydraulic and pneumatic supercharging system MAXIMATOR German
Frequency converter KINCO China
Pneumatic components(cylinder/valve) ARTAC Taiwan
Quick exhaust valve/Vacuum generator SMC Japan SMC
Travel light OMRON Japan
Optical fiber OMRON Japan

High Speed Insulating Glass Production Line Butyl Extruder Machine 2High Speed Insulating Glass Production Line Butyl Extruder Machine 3High Speed Insulating Glass Production Line Butyl Extruder Machine 4

►►►Filter system                                 ►►►Butyl change system                     ►►►Auto Spacer width control system



High Speed Insulating Glass Production Line Butyl Extruder Machine 5

Butyl Extruder Machine LJTB 03

High Speed Insulating Glass Production Line Butyl Extruder Machine 6

Main feature

• PLC control system, touch screen interface

• Frequency control system

• Arc frame coating structure

• Imported pneumatic and hydraulic supercharging system

• Automatic centering and clamping structure

• Loading capacity up to 14KG, saving time for feeding glue

• Adopt five steps to control convey

• Preheating function,glue cylinder limit function,alarm system

• Covey and gluing mechanism adopts the latest design

Technical data



Squeeze pressure 10-18MPa
Temperature 110~140℃
Aluminum spacer width 6A-27A
Speed 0-40m/min
Diameter of butyl cylinder 200mm
Air supply 0.4m³/min
Air pressure ≥0.6MPa
Total power 380V, 5KW,50HZ
Dimension 2600×680×1100mm(L×W×H)
weight 650kg


High Speed Insulating Glass Production Line Butyl Extruder Machine 7

High Speed Insulating Glass Production Line Butyl Extruder Machine 8

High Speed Insulating Glass Production Line Butyl Extruder Machine 9

High Speed Insulating Glass Production Line Butyl Extruder Machine 10
