|Production Name:||Vertical Glass Washing Machine||Machine Model:||LJQX2500|
|Maximum Glass Size:||2500*3500||Minimum Glass Size:||280mm*400mm|
|Glass Thickness:||3 - 15mm||Material:||Stainless Steel|
glass cleaning machine,
automatic glass cleaning machine
LIJIANG glass washing machine has 3 sections: glass transfer section, washing and drying machine, inspection section.
1. It is made of stainless steel, the brush bearing is made of Harbin stainless steel, which is famous in China;
2.3 pairs of soft brush is equipped with 0.1mm brush wire;
3. Use European anti noise mode to reduce noise;
Drying section :
1. The front and rear extrusion wheels are powered to keep different sizes of glass can pass quickly and smoothly;
2. The new type air knife could adjusts the size of the air vent through the aluminum duck beak; reduces the number of adjusting screws, ensures that each screw is not loose, and avoids the resonance of the air knife.
3. The width of the air knife can be adjusted automatically according to the thickness of the glass.
|Glass washing speed||2-10m/min|
|Glass conveyor speed||45m/min|
|Washing brushes||3 pairs|
|Water supply||Water consumption:0.5t/h conductivity:40μs/cm|
|Air supply||Flow: 0.8m/min|
|Total power||3P 380V 50Hz (Optional)|
1. Maximum washing size : 2000mm*2500mm / 2500mm*3500mm / 3000mm*4000mm
2. Glass thickness : 3- 15mm / 3- 18mm / 3- 19mm
3. Brushes : 6 pieces ; soft brushes / hard brushes
4. Washing low-e glass is optional
5. Pre - washing machine is optional
6. Changing big power motor is optional
