Name: Thickness 2mm-25mm Horizontal Glass Washing Machine For Glass Deep Processing
Brand: Jinan Lijiang Automation Equipment Co., Ltd.
SKU: LJWBQJ2500
Price: 23.00 USD
Availability: InStock

Home > Products > Horizontal Glass Washing Machine >

Thickness 2mm-25mm Horizontal Glass Washing Machine For Glass Deep Processing

25mm Horizontal Glass Washing Machine

2mm Horizontal Glass Washing Machine

Deep Processing Horizontal Glass Washing Machine

Place of Origin:

CHINA

Brand Name:

LIJIANG GLASS

Certification:

Model Number:

LJWBQJ2500

Request A Quote

Product Details

Voltage:

Can Be Request, 380v

Power:

42Kw, 15kw

Dimension(L*W*H):

6260*4800*3100, 5700*3600*2650mm

Weight:

3940Kg, 1500kg

Glass Thickness:

2-25mm, 3-18mm

Highlight:

25mm Horizontal Glass Washing Machine

2mm Horizontal Glass Washing Machine

Deep Processing Horizontal Glass Washing Machine

Payment & Shipping Terms

Minimum Order Quantity

one

Price

USD 25,000 to USD 22,000

Packaging Details

container

Delivery Time

15 working days

Payment Terms

L/C, T/T

Supply Ability

10 units per month

Horizontal Glass Washing And Drying Machine For Insulating Glass Processing

Get Best Price

Horizontal Flat Glass Washing Machine For Insulating Glass Processing

Get Best Price

2500mm 2650mm Horizontal Flat Glass Washing Machine Easy Operate

Get Best Price

Video

Thickness 2mm-25mm Horizontal Glass Washing Machine For Glass Deep Processing

Get Best Price

Contact Now

Product Description

Horizontal Automatic Glass Washing and Drying Washer and Dryer Cleaner Cleaning Machine for Glass Deep Processing

Automatic Horizontal Glass Washing and Drying Machine LJWBQJ2500 used for cleaning and drying the upper and lower surfaces of ordinary plate glass and high quality low-e glass,it is composed of incoming segment, cleaning air-drying segment and out goingsegment.

Structural characteristics:

Transfer rubber covered roller adopt gear revolve, stable and convenience maintain, the above and bottom hairbrush roller adopt two motors for transfer motion, stable transfer, the belt are durability.

Machine transmission are adopt vulcanized rubber cover roller structure (prohibit acidic liquid get in touch), washing part, drying part whole lifting automatically, the maximum lift range is 400mm, in order to adapt washing different glass thickness,continence for cleaning and replace the hairbrush.

3.Drying part, air drying system equip two pairs of air knife, a pair of straight air knife and skew air knife cooperate

application, high pressure blower can completely drying the glass surface, large lateral wind power, good air drying effect.(two cold wind air knife, no need to heat). Keep after washing product can meet the requirement of the drying level, the upper air knife through controlling system adjust lifting,improve the drying effect. Equip high pressure blower 22kw, air intake through air filtering, large wind power, good drying effect, follow the washing and drying part lifting automatically, to ensure the after washing products can meet the requirement of the drying level.
