Product Details:
Place of Origin: China
Brand Name: LIJIANG
Certification: CE
Model Number: LJBZ2535
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD120000/set
Packaging Details: wooden box
Delivery Time: 5-8work days
Payment Terms: L/C, T/T
Supply Ability: 10sets/month

CNC Glass Cutting Produce Line, automatic insulating glass production line

Description
Name: Automatic Insulating Glass Production Line LJBZ2535 Max. Glass Size: 2500mm*3500mm
Min. Glass Size: 280mm*400mm Glass Thickness: 3-15mm
Insulating Glass Thickness: 50mm / 60mm Glass Washing Speed: 2-10m/min
Glass Conveyor Speed: 45m/min Washing Brushes: 3 Pairs
Water Supply: Water Consumption:0.5t/h Conductivity:40μs/cm Air Supply: Flow: 0.8m/min
Air Pressure: ≥0.8MPa Total Power: 3P 380V 50HZ 40KW
Dimension: 23500*3500*3700mm Weight: 6500kg
High Light:

double glazing production

,

insulating glass line

Smart Vertical Edge Deleting Machine LJDM2545



Products Description


CNC Glass Cutting Produce Line, automatic insulating glass production line 0

Main technical parameter

Max. glass size2500mm*3500mm
Min. glass size280mm*400mm
Glass thickness3-15mm
Insulating glass thickness50mm / 60mm
Glass washing speed2-10m/min
Glass conveyor speed45m/min
Washing brushes3 pairs
Water supplyWater consumption:0.5t/h conductivity:40μs/cm
Air supplyFlow: 0.8m/min
Air pressure≥0.8MPa
Total power3P 380V 50HZ 40KW
Dimension23500*3500*3700mm
Weight6500kg




Electrical parameters

NAMEORIGINBRAND
Transfer motorGermanySIEMENS
Brush motorGermanySIEMENS
Servo motorGermanySIEMENS
PLCGermanySIEMENS
Low voltage electrical applianceGermanySIEMENS
Frequency converterGermanySIEMENS
Micro SwitchTaiwanTEND
Button and indicator lightFranceSCHNEIDER
Touch screenTaiwanWEINVIEW
Intermediate relayJapanOMRON
Water pumpChinaLINGXIAO
GuideTaiwanHIWIN
Pneumatic ComponentsTaiwanAIRTAC
Electric gaugeChinaMIRAN
Photoelectric switchKoreaAUTONICS




Detailed description


1.Hot water system and water filtration systemCNC Glass Cutting Produce Line, automatic insulating glass production line 1
Due to the different water quality in different countries, in
order to ensure that the glass is sufficiently clean, please
use the air heating system, and the glass must be cleaned
with soft water. In addition, the water filtration system is
used for water recycling, which can save water and keep
the water quality clean.



































2.The special structure inside the washing machine can automatically recognize the glass thickness. Can quickly transfer glass of different thicknesses, thereby increasing production speed. According to the test, it takes only 22 seconds to produce 1m * m insulating glass.



3.The pressing box uses servo motor and timing belt to support pressing IG units.
Servo motor can be accurately calculated the thickness of the glass and aluminum spacer. Compared with traditional hydraulic station, servo motor can guarantee the precise working pressure and protect the glass from damage, at the same time increasing the working speed.

Timing belt is jagged, making the pressing more accuratly.






Certifications

CNC Glass Cutting Produce Line, automatic insulating glass production line 2CNC Glass Cutting Produce Line, automatic insulating glass production line 3CNC Glass Cutting Produce Line, automatic insulating glass production line 4CNC Glass Cutting Produce Line, automatic insulating glass production line 5



Packing&Delivery



To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.


CNC Glass Cutting Produce Line, automatic insulating glass production line 6
CNC Glass Cutting Produce Line, automatic insulating glass production line 7
CNC Glass Cutting Produce Line, automatic insulating glass production line 8
CNC Glass Cutting Produce Line, automatic insulating glass production line 9


Company Profile


CNC Glass Cutting Produce Line, automatic insulating glass production line 10


Jinan Lijiang Automation Equipment Co., Ltd. (Lijiang Glass Factory) is located in the beautiful spring city of Jinan. It is an enterprise integrating R & D, sales and service of glass processing equipment.
The company is committed to drawing on the experience of famous experts, establishing a research and development center, cooperating with well-known domestic and foreign enterprises, introducing advanced technology, etc., and is committed to building high-grade insulating glass machinery and equipment. . Now, our friendly partners include Northern Glass, Xinfuxing, Yaohua, Dalian Huaying, Beijing Guanhua, Shanghai Haojing, Sichuan Lihehua and other well-known enterprises. Since the establishment of the company, our products have been exported to nearly 30 countries and regions in Europe, America, South America, Middle East, Southeast Asia, India and so on. At the same time, the company cooperates with Shandong University and other well-known domestic research institutions to continuously improve the level of technical research. So far, we have independently produced vertical automatic insulating glass production line with filling gas, vertical insulating glass sealing robot, automatic interval bending machine, automatic dehumidifying filling machine and new automatic butyl rubber extruder, its technology and The quality reaches the highest level of leadership in China.


After sale

CNC Glass Cutting Produce Line, automatic insulating glass production line 11
1. The whole machine is guaranteed for one year.
2. 24-hour email technical support.
3. Friendly English software, user manual and detailed video / CD.
4. We will provide all the spare parts needed for equipment maintenance.
A professional after-sales service team provides face-to-face training and installation services to customer factories.

CNC Glass Cutting Produce Line, automatic insulating glass production line 12
