Product Details
Name:
Desiccant Filling Machine
Air Source:
≥0.65MPa
Power Supply And Power Consumption:
AC220V 50Hz 1.8KW
Molecular Sieve Diameter Needed:
0.5-0.9mm
Dimension:
1300mm*1100mm*3650mm
Highlight:

double glazing production

,

insulating glass line

Payment & Shipping Terms
Minimum Order Quantity
1sets
Packaging Details
Wooder
Delivery Time
20
Supply Ability
35sets
Product Description



Desiccant Filling Machine



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 0



APPLICATION



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically

in the spacer frames, filling desiccant and sealant. Desiccant Filling Machine control system

adopts Germany Siemens, so the speed of filling is quick and stable operation ensure the

valid closure property of sealant. Desiccant Filling Machine improves quality of insulating glass,

it’s a necessary equipment in the process of insulating glasses.



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 1



Main technical parameter





Name Brand Name Brand
PLC German SIEMENS Triplet TAIWAN AIRTAC
Low voltage electrical apparatus German SIEMENS Solenoid valve TAIWAN AIRTAC
Sensor Korea AUTONICS Gas driller Taiwan BOA
Guide Taiwan TBI Switch power Taiwan TEND





Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 2



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 3



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 4



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 5



All the electrical wires have the ID number,it can match with specification , also it will be very

easy for the further communication in the after sales service .



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 6



Filling aluminum frame’s maximum size 2500mm*2500mm
Filling aluminum frame’s minimal size 300mm*250mm
Article aluminum specifications 5.5-24mm
Air source ≥0.65MPa
Power supply and power consumption AC220V 50Hz 1.8KW
Molecular sieve diameter needed 0.5-0.9mm
Dimension 1300mm*1100mm*3650mm



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 7



Until 2019, we exported glass machines and materials to America, South America, Europe, the Middle East,

India and so on, nearly 30 countries and regions. We have established a perfect international business

relationship with 10 powerful agents and made an endeavor together to build a famous international brand

to the world. Kation-Tech, with craftsmanship, profession and honesty, wins the future with you together!



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 8



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 9



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 10



More details please search www.lijiang-glass.com

Q: What's the payment term?

A: T/T, L/C and other payment terms could be negotiated.

Q: About this Machine,What’s the guarantee ?

A:1)Our guarantee for 12 months.

2)24 hour’s technical support by email or calling

3)English manual and video tutorial

4)We will provide the consumable parts at an agency price

5)24 hours on line service each day, free technical support.

Q:How about your warranty?

A:Generally, our warranty is one year. Within the warranty period, we can offer technique support,

Feedback to you within 24 hours and help you to repair your problem controller freely, even it's not from our factory

Q:Can we visit your factory before order?

A:Yes, we warmly welcome and sincerely invite you or your team to visit our factory, we will help to arrange

hotel and pick up you from airport.

Q: What's the delivery term?

A:At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working

days after deposit receipt. If you are in urgent need, we can consider making special arrangement for you.



Desiccant Filling Machine can automatically achieve actions of drilling holes automatically in the spacer frames 11
