Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE

Certification
China Jinan Lijiang Automation Equipment Co., Ltd. certification
China Jinan Lijiang Automation Equipment Co., Ltd. certification
Customer Reviews
Our using experience proves that your equipment is of a high level. Especially thank you for your professional service, the service is quite good. We hope your company keep the way all the time.

—— Mr. Caner -CEO

Good machines, good service, Good people.

—— Mr. Flavio - CEO

lijiang machines is very stable , we purchase more than 3 IG line from them , it's good . service is very nice , 24 hours online with fast reply .

—— Mr Dilip

I am from vietnam , lijiang is my china machine supplier, from last three years we start cooperation ,till now all good .

—— Mr THO

This is Robin from birkan engineering company india , we are big manufacturer for rail way glass , last two year we bought one argon gas line , and other accessary machines, very nice machines , very nice service . it improved double time working efficiency . Thanks for lijiang support .

—— Mr Robin

It's my second time buy lijiang machines , their machine quality and service are excellent , so lucky have this good and honest supplier.

—— Mr Abdul

when buy the machines from oversea market, always wondering how is the quality , how is the service, how is their person , how should do if they are lier , But finially close order with them , everything is excellent .

—— MR Dave

Being in the glass industry for over 20 years ,the one thing i can tell you is that machines don't speak ,but you can tell a lot about the manufacturer that make them through using the machines. Well,there is nothing unpleasing i can tell about Lijiang Automatic Co.

—— Mr SANDEEP

What makes me a loyal customer of Lijiang is their professionalization ,efficiency ,punctuality and fast reaction on after-service .Hope we can always have this in the future.

—— MR BULBUL

A perfect combination of quality,price and service .Who doesn't like to work with a company like this ?

—— MS JENY

I'm Online Chat Now

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE
Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE

Large Image :  Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE

Product Details:
Place of Origin: China
Brand Name: LIJIANG
Certification: CE
Model Number: LJTJ2540
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: wooden box
Delivery Time: 5-8work days
Payment Terms: L/C, T/T
Supply Ability: 20sets/month

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE

Description
Name: Vertical Insulating Glass Sealing Robot Max.glass Size: 2500mm
Min.glass Size: 170mm*400mm (2000mm Machine) Glass Thickness: 12-56mm
Working Speed: 5-40m/min Air Pressure: 0.6-0.8MPa
Squeeze Pressure: <350kg/m³ Plane Angle: 6°- 9°
Max Glass Weight: 400kg Voltage Power: 380V 12kw
Overall Dimension: 8700mm*2000mm*3500mm
High Light:

silicone extruder machine

,

double glazing equipment

Vertical insulating glass sealing robot



Products Description

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 0

Sealing the insulating glass twice, sealing and bonding the insulating glass, and also protecting the first sealing layer.

Main technical parameter





Max.glass size 2500mm*4000mm
Min.glass size 170mm*400mm (2000mm machine)
Glass thickness 12-56mm
Working speed 5-40m/min
Air pressure 0.6-0.8MPa
Squeeze pressure <350kg/m³
Plane angle 6°- 9°
Max glass weight 400kg
Voltage power 380V 12kw
Overall dimension 8700mm*2000mm*3500mm




Equipment advantages

  • The minimum and maximum glass sizes can be selected
  • Use 8 servo motors
  • Adopting Japanese Yaskawa servo control system, stable performance
  • Linear adjustment automatically measures glass size, glue depth and glue speed
  • Using synchronous belt, stable transmission and accurate position
  • High standardization of spare parts and high precision to ensure that the machine can be used for a long time
  • The glass corner is full, no bubbles, smooth surface, no need
  • Fully automatic high efficiency machine
  • The new scraper design is especially suitable for making the train IG have very flat sides and corners, and no bubbles.
  • Automatically repair the bright glass corners
  • Conveying is stable, without scratches and pollution
  • Single function parts have manual function, easy to adjust
  • Special-shaped IG unit (optional)
  • Stepped IG unit with four sides (optional)
  • Double and triple IG device



Product picture display



Ø One Set of Pump A & Pump B

Equipped with single A component and single B component. Glue A and B automatic mixing, automatic ratio.



Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 1





Ø Two Sets of Pump A & Pump B

Equipped with two sets of A components and two sets of B components, which can be used for two kinds of different sealants, such as silicone rubber, polysulfide rubber, silicone structural adhesive and so on.

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 2





Ø Back Glue Device

When the pressure increasing, more Glue B will flow back automatically, saving materials.

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 3







Ø Dyad Body Device

The dyad body device has two functions. The left one is used for filtering impurities and moisture when filling gas into , then the right one plays the role of lubrication.

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 4







Certifications

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 5Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 6Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 7Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 8



Packing&Delivery



To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.


Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 9
Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 10
Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 11
Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 12


Company Profile


Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 13


Jinan Lijiang Automation Equipment Co., Ltd. (Lijiang Glass Factory) is located in the beautiful spring city-Jinan. It is an enterprise integrating R & D, sales and service of glass processing equipment. Due to the proximity to the Beijing-Shanghai high-speed rail, the transportation is very convenient.

The company is committed to drawing on the experience of famous experts, establishing a research and development center, cooperating with well-known domestic and foreign enterprises, introducing advanced technology, etc., and is committed to building high-grade insulating glass machinery and equipment. Now, our friendly partners include Northern Glass, Xinfuxing, Yaohua, Dalian Huaying, Beijing Guanhua, Shanghai Haojing, Sichuan Lihehua and other well-known enterprises. Since the establishment of the company, our products have been exported to nearly 30 countries and regions in Europe, America, South America, Middle East, Southeast Asia, India and so on. At the same time, the company cooperates with North China Industrial Group, Shandong University and other well-known domestic research institutions to continuously improve the level of technical research. So far, we have independently produced a vertical automatic insulating glass production line with filling gas, a vertical insulating glass sealing robot, an automatic interval bending machine, an automatic dehumidifying filling machine and a new automatic butyl rubber extruder, Its technology and quality have reached the highest level of leadership in China.

With the rapid development of the insulating glass industry, Lijiang looks forward to working with you for a win-win situation and creating a new world together.



After sale

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 14
1. The whole machine is guaranteed for one year.
2. 24-hour email technical support.
3. User friendly English software, user manual and detailed video / CD.
4. We will provide all the spare parts needed for equipment maintenance.

A professional after-sales service team provides face-to-face training and installation services to customer factories.

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 15

Automatic Sealant Extruder Vertical Insulating Glass Sealing Robot With CE 16
