Custom Horizontal Glass Washing Machine with Soft Low e Brushes

Custom Horizontal Glass Washing Machine with Soft Low e Brushes
Custom Horizontal Glass Washing Machine with Soft Low e Brushes Custom Horizontal Glass Washing Machine with Soft Low e Brushes Custom Horizontal Glass Washing Machine with Soft Low e Brushes Custom Horizontal Glass Washing Machine with Soft Low e Brushes

Large Image :  Custom Horizontal Glass Washing Machine with Soft Low e Brushes

Product Details:
Place of Origin: China
Brand Name: Lijiang
Certification: CE
Model Number: LJWBQJ2500
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable,
Packaging Details: woodencontainer
Delivery Time: 10days
Payment Terms: L/C, T/T
Supply Ability: 10set/month

Custom Horizontal Glass Washing Machine with Soft Low e Brushes

Description
Name: Horizontal Glass Washing And Drying Machine Material: Stainless Steel For Washing Parts
Brush: Sofe For Low-e Glass
High Light:

horizontal glass washer

,

automatic glass cleaning machine

Custom Horizontal Glass Washing Machine with Soft Low e Brushes 0

                            LIJIANG GLASS- FOR WORLD GLASS MACHINE USER SERVICE



Custom Horizontal Glass Washing Machine with Soft Low e Brushes 1

Horizontal Glass Washing and Drying Machine LJWBQJ2500

Custom Horizontal Glass Washing Machine with Soft Low e Brushes 2

Features

  1. Horizontal Glass Washing and Drying Machine LJWBQJ2500,can be equipment with pretreatment for temper furnace,laminated and insulating glass furnace;all stainless steel clean room,drying room,water tanks pumps, air knife,water pipe,cover,fan housing etc,.,ensure machine durable,not rust.
  2. Hand made of aluminum alloy support structure,combination of installation,no rust.
  3. High-precision lifting system,digital display raising height of the upper portion of the machine.

4. Three pairs high-quality nylon brushes,brushed the first two pairs brushed can raised to used for LOW-E glass cleaning.

5. All the machines conveyor rollers is vulcanized rubber rollers.

6. Main driving realize step-less speed regulating by inverter and speed gear transmission to ensure stable and reliable.







Custom Horizontal Glass Washing Machine with Soft Low e Brushes 3

Custom Horizontal Glass Washing Machine with Soft Low e Brushes 4

Technical parameters:

1. Maximum glass width: 2500mm (effective maximum: 2650mm)

2. Minimum glass specification: 400mm×400mm (limited to single row on left and right sides)

3. Glass thickness: 3mm-25mm (digital display)

4. Speed range: glass thickness within 3-25mm Vmax=1-12m/min

5. Main drive, brush speed regulation method: frequency control

6. Table height :900±25mm



Custom Horizontal Glass Washing Machine with Soft Low e Brushes 5



7. Total power: 42KW(water-bearing wind heating: 15KW)







8. Water source: self-circulation, tap water (according to civil water standards) and deionized water water supplement (deionized water equipment shall be provided by the buyer)





9. Power source: 380V 50Hz







Maximum glass width 2500mm (effective maximum: 2650mm)
Minimum glass specification 400mm×400mm (limited to single row on left and right sides)
Glass thickness 3mm-25mm (digital display)
Speed range glass thickness within 3-25mm Vmax=1-12m/min
Main drive, brush speed regulation method frequency control
Table height 900±25mm
Total power 42KW(water-bearing wind heating: 15KW)
Water source self-circulation, tap water (according to civil water standards) and deionized water water supplement (deionized water equipment shall be provided by the buyer)
Power source 380V 50Hz
Dimensions (length × width × height) approximately 6260*4800*3100mm
Weight 3940kg

Custom Horizontal Glass Washing Machine with Soft Low e Brushes 6Custom Horizontal Glass Washing Machine with Soft Low e Brushes 7

Drying Knife design                                                          ►Safty electrical connecting design

Custom Horizontal Glass Washing Machine with Soft Low e Brushes 8Custom Horizontal Glass Washing Machine with Soft Low e Brushes 9

Stainless steel for washing parts                          ►Profile construction design


Custom Horizontal Glass Washing Machine with Soft Low e Brushes 10

Custom Horizontal Glass Washing Machine with Soft Low e Brushes 11
