Safety Low E Glass Edge Deleting Machine With Six Servos Control System

Safety Low E Glass Edge Deleting Machine With Six Servos Control System
Safety Low E Glass Edge Deleting Machine With Six Servos Control System Safety Low E Glass Edge Deleting Machine With Six Servos Control System Safety Low E Glass Edge Deleting Machine With Six Servos Control System

Large Image :  Safety Low E Glass Edge Deleting Machine With Six Servos Control System

Product Details:
Place of Origin: CHINA
Brand Name: LIJIANG GLASS
Certification: CE
Model Number: LJCM2545
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Container
Delivery Time: within 30 days
Payment Terms: L/C, T/T
Supply Ability: 20 sets/month

Safety Low E Glass Edge Deleting Machine With Six Servos Control System

Description
Production Name: Low-e Glass Deleting Machine Max.glass Processing Size: 2500*4500mm
Min.glass Processing Size: 350*500mm Glass Thickness: 3-15mm
Edge Deleting Width: 10-150mm Glass Conveyor Speed:: 2-29m/min
Edge Deleting Speed: 0-15mm/min Abrasive Wheel Width: 10/12/15
High Light:

glass grinding equipment

,

glass edge polishing machine

Low-e Glass Edge Deleting Machine with Six Servos control system



Automatic Low-e glass edge deleting machine adopts German Siemens brand spare parts, which can intelligently remove the edge of Low-E, and its width can be adjusted by 10-150 mm.


Application of Glass edge deletation

Edge Deleting machine is used for  Insulating glass processing machine to Deleting low-e glass edge.



Main feature of Low-E film removal machine

1.Glass film deleting machine can Auto measure the size and the thickness

2.Auto-modified function,The pressure of edge deleting is stable and adjustable

3.Glass Grinding machine can Auto distinguish coating side of low-e glass.

4.Glass processing machine adopt PLC control system,touch screen interface

5.Control system intelligently memorize batch processing function

6.Safety protection device auto-dedusting function



Technical data



Max.glass processing size 2500*4500mm
Min.glass processing size 350*500mm
Glass thickness 3-15mm
Edge deleting width 10-150mm
Glass conveyor speed 2-29m/min
Edge deleting speed 0-15m/min
Abrasive wheel width 10/12/15mm
Air pressure ≥0.8MPa
Total power 3P 380V 50Hz 13.35KW
Dimension 9700*2500*3400mm



Safety Low E Glass Edge Deleting Machine With Six Servos Control System 0

Safety Low E Glass Edge Deleting Machine With Six Servos Control System 1



Company Introduction

Jinan Lijiang Automation Equipment Co., Ltd. is located in the beautiful spring

city------Jinan. It is an enterprise which integrated glass processing equipment research and development, sales and service into a whole. As it is close to Beijing-Shanghai high-speed rail, the transportation is very convenient.



The company is committed to building high-end insulating glass machinery and equipment by learning from famous experts, establishing the research and development centers, cooperating with domestic and foreign well-known enterprises, importing advanced technology and so on. Now, our friendly partners include North Glass, Xin Fuxing, Yaohua, Dalian Huaying, Beijing Guanhua, Shanghai Hao Jing, Sichuan Li Hehua and other well-known enterprises. Since the establishment of the company, our products have been exported to Europe, America, South America, the Middle East, Southeast Asia, India, nearly 30 countries and regions. At the same time, our company worked with the well-known domestic research institutes, such as the North China Industrial Group, Shandong University and others, to constantly improve the level of technical research. So far, we have independently produced the vertical automatic IG production line with filling gas on line, the vertical IG sealing robot, the automatic spacer bending machine, the automatic desiccant filling machine and the new fully automatic butyl extruder machine, its technology and quality have reached the highest leading level in China.



With the rapid development of insulating glass industry, LIJIANG is looking forward to working with you for win-win situation and jointly creating a new world.

Safety Low E Glass Edge Deleting Machine With Six Servos Control System 2
