Vertical Low E Glass Film Deletion Machine For Making Double Glazing Glass

Vertical Low E Glass Film Deletion Machine For Making Double Glazing Glass
Vertical Low E Glass Film Deletion Machine For Making Double Glazing Glass Vertical Low E Glass Film Deletion Machine For Making Double Glazing Glass Vertical Low E Glass Film Deletion Machine For Making Double Glazing Glass

Large Image :  Vertical Low E Glass Film Deletion Machine For Making Double Glazing Glass

Product Details:
Place of Origin: JINAN, CHINA
Brand Name: LIJIANG GLASS
Certification: CE
Model Number: LJCM2545
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Container
Delivery Time: 45days
Payment Terms: L/C, T/T
Supply Ability: 30 sets per month

Vertical Low E Glass Film Deletion Machine For Making Double Glazing Glass

Description
Production Machine: Automatic Low-e Film Deletion Machine Max Glass Size: 2500mm*4500mm
Min Glass Size: 350mm*500mm Deletion Speed: 0 - 15m/min
Deletion Width: 10mm - 150mm Wheels Size: 10mm, 12mm, Or 15mm
High Light:

double glazing production

,

insulating glass line

Vertical low-e glass film deletion machine for making double glazing glass

Vertical low-e glass film deletion machine for making double glazing glass is used to delete the film on the low-e glass with fast speed. The deletion machine can delete rectangle glass and shape glass, it has 6 servo motors.



Max glass size  2500mm*4500mm
Min glass size  350mm*500mm
Wheels width  10mm, 12mm, 15mm
Deletion width  10mm - 150mm
Glass thickness  3-15mm





1. What is the function of the film deletion machine?



The main function is to remove the edge film of Low-e glass



2. Why should delete the low-e glass film?



To prevent the film from oxidizing when the insulating glass is synthesized.



3. What glass needs to be deleted?

When off-line Low-e glass



4. In addition to using the vertical film deletion machine to delete film, what other ways can remove film?



Manual, horizontal edge grinding machine, bilateral edge grinding machine, four-edge edge grinding machine, cutting machine, etc



5. What are the advantages of using our film separator? What are the disadvantages? What are the advantages of using other methods? What are the disadvantages?



With our vertical film rdeletion machine can be connected to use, save labor, film removing effect is good, glass flatness is good, can be in addition to the large plate glass. Disadvantage is to increase the length of the whole line, cover a large area.

Manual film removal effect is poor, slow speed. The others are film removal before toughening, because the heating time of white glass and Low-e glass during toughening is not the same, it will cause glass deformation, advantage does not need too high investment.



6. Is glass before toughening divide film is good still after toughening divide film is good? Why is that?



After toughening, film removal is good, glass deformation is small.



7. What brand of PLC, servo motor driver, frequency converter is used to deletion machine?



At present, delta PLC servo motor and drive, inverter delta and schneider



8. How many sections does the film deletion machine divide into? What are the dimensions of each segment? What are the roles?



The film deletion machine is divided into three sections, the first or the third section is  2.2 meters, mainly for glass input and output and storage of glass, the middle section 5.3 meters, mainly for film deletion.



9. Can the device distinguish the low-e film surface?



The film layer can be detected automatically.



10. Do you need to input the length and width of the glass when using the film remover?



No, it's automatically detected.
