10m/min Insulating Glass Production Line Horizontal Washer

10m/min Insulating Glass Production Line Horizontal Washer
10m/min Insulating Glass Production Line Horizontal Washer 10m/min Insulating Glass Production Line Horizontal Washer 10m/min Insulating Glass Production Line Horizontal Washer

Large Image :  10m/min Insulating Glass Production Line Horizontal Washer

Product Details:
Place of Origin: China
Brand Name: Lijiang
Certification: CE
Model Number: LJLBQJ2500
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable,
Packaging Details: wooden case or container
Delivery Time: 20days
Payment Terms: T/T, L/C
Supply Ability: 10set/month

10m/min Insulating Glass Production Line Horizontal Washer

Description
Name: Vertical Washing And Drying Machine Material: Stailess Stell Touching Water Part
Advantage: Brush For Low-e Feature: Easy Opration
High Light:

Horizontal Insulating Glass Production Line

,

IG Glass Horizontal Washer

,

Insulating Glass Horizontal Washer

Automatic Vertical And Horizontal Washing And Drying Machine Easy Opration Glass Cleaning

10m/min Insulating Glass Production Line Horizontal Washer 0



      LIJIANG GLASS- FOR WORLD GLASS MACHINE USER SERVICE



10m/min Insulating Glass Production Line Horizontal Washer 1

Glass Washing Machine LJLBQJ2500

10m/min Insulating Glass Production Line Horizontal Washer 2



Automatic Horizontal Glass Washing and Drying Machine LJWBQJ2500 used for cleaning and drying the upper and lower surfaces of ordinary plate glass and high quality low-e glass,it is composed of incoming segment, cleaning air-drying segment and out goingsegment.
10m/min Insulating Glass Production Line Horizontal Washer 310m/min Insulating Glass Production Line Horizontal Washer 4
  • In the washing machine ,there three pairs soft brushes all can wash low-e glass, four pairs of water spray.
  • The material in the washing and drying section all made by stainless steel.
  • The main power consumption is mostly appear in the washing and drying section of the IG line.
  • The air knife is float design , it always keep the right and suitable distance between the glass and air knife in the press and design section
  • The transfer wheel in the washing and drying section : The front and back transfer wheel are all moved, all actively transfered. No mater the glass size is big or small , it all guarantee the glass pass through smoothly
  • The axle and bearing of brushes are stainless steel , that all keep the machine can washing well and live for a long time.
  • The who drying machine use the sound insulation design.can reduce the noise.

10m/min Insulating Glass Production Line Horizontal Washer 510m/min Insulating Glass Production Line Horizontal Washer 6
►The drying roon system



10m/min Insulating Glass Production Line Horizontal Washer 710m/min Insulating Glass Production Line Horizontal Washer 8

The water tank system and water heating fuction

10m/min Insulating Glass Production Line Horizontal Washer 910m/min Insulating Glass Production Line Horizontal Washer 10

Using Europe's advanced anti-noise system to create a good working environment for employees.The noise can be controlled below 90 decibels by using nylon gear and sponges.



10m/min Insulating Glass Production Line Horizontal Washer 1



Vertical Insulating Glass Production Line LJBZ2535G

10m/min Insulating Glass Production Line Horizontal Washer 12



Main Features:

• Adopt SIEMENS control system, keep stable performance

• PLC control system, touch screen interface

• Automatically adjust the depth of glue with digital display

• Using servo to control system, modular function, superposition function

• Applicable to produce stepped IG, triple IG and shaped IG

• Two pieces of IGU can be made and filled with argon gas in one time (Optional)

• Min & Max glass sizes can be optional

Technical data

Max. glass size 2500mm*3500mm
Min. glass size 280mm*400mm
Glass thickness 3-15mm / 19mm
Insulating glass thickness 50mm / 60mm
Glass washing speed 2-10m/min
Glass conveyor speed 45m/min
Washing brushes 3 pairs
Water supply Water consumption:0.5t/h conductivity:40μs/cm
Air supply Flow: 0.8m/min
Air pressure ≥0.8MPa
Total power 3P 380V 50HZ 40KW
Dimension 23500*3500*3700mm
Weight 6500kg

Electrical parameters

NAME ORIGIN BRAND
PLC Germany SIEMENS
Low voltage electrical appliance Germany SIEMENS
Frequency converter Germany SIEMENS
Servo motor Japan FUJI
Photoelectric switch Germany SICK
Micro Switch Taiwan TEND
Button and indicator light France SCHNEIDER
Touch screen Taiwan WEINVIEW
Intermediate relay Japan OMRON
Brush motor China QINGHUA
Water pump China LINGXIAO
Guide Taiwan HIWIN
Pneumatic Components Taiwan AIRTAC
IG line without filling gas online



NAME ORIGIN BRAND
Servo motor Germany SIEMENS
PLC Germany SIEMENS
Low voltage electrical appliance Germany SIEMENS
Frequency converter Germany SIEMENS
Transfer motor Taiwan LINHAI
Brush motor Taiwan LINHAI
Water pump China LINGXIAO
Guide Taiwan HIWIN
Pneumatic Components Taiwan AIRTAC
Electric gauge China MIRAN
Photoelectric switch Germany SICK
Micro Switch Taiwan TEND
Button and indicator light France SCHNEIDER
touch screen Taiwan WEINVIEW
Intermediate relay Japan OMRON
IG line with gas filling online

10m/min Insulating Glass Production Line Horizontal Washer 13



10m/min Insulating Glass Production Line Horizontal Washer 1410m/min Insulating Glass Production Line Horizontal Washer 1510m/min Insulating Glass Production Line Horizontal Washer 1610m/min Insulating Glass Production Line Horizontal Washer 17
