Automatic Bending Machine Aluminum Spacer Bending Cutting Machine

Use an automatic spacer bend cutting machine to bend and cut the spacer frame inside the insulated glass unit. The automatic bending machine is one of the auxiliary devices for making insulating glass. Automatic aluminum bending has many optional features. Printing of labels for spacer data, printing of logos and dates, etc. The automatic spacer bar bending machine can bend stainless steel rod, warm edge spacer bar (plastic spacer bar).

Main feature of automatic bending machine

• Connect to ERP system (Optional)

• USB input function, read the excel format file directly

• Automatically drill holes for filling argon gas (Optional)

• Spacer printing code function (Optional)

• Printing label sticker function (Optional)

Details of the automatic spacer bending machine :

•
• 4 Specifications You can set the size data for 32 size glass plates (8 types for each specification). The machine can calculate aluminum frame data automatically according to each size. Continuous processing greatly improves efficiency and speed.
• CNC servo supply system.
• With the exception of start/stop operations, all operations are completed on the touch screen and the operation console can be moved. Chinese operation interface, easy to operate, natural and easy to understand.
• The bending speed is automatically adjusted according to the size of the aluminum frame, avoiding the large frame frame deformation, ensuring fast and continuous small frame.
• Automatic connection of aluminum spacer bars and intelligent avoidance design of aluminum bar joints (avoid bends and cuts in the joints).
• High-speed continuous production function, the operator only has to check the material in the material trough and remove the folded aluminum frame from the bending machine (the machine has a failure alarm function that can show the location and cause of the failure) .. The bending machine automatically stops after processing the set number.
• A rational judgment function for aluminum frame data, rejecting unreasonable data processing and speeding up.
• The boot system is completely self-resetting.
• The automatic cutting of the aluminum frame has been completed.
• Quick maintenance adjustment panel design.
• Hibernate energy saving function and emergency stop protection.
• You can manually operate all features to meet your debugging and maintenance needs.
• No Material Prompt, Sleep Prompt, Fault Prompt, Work Prompt, No Material in Process, Automatic Stop to Wait for Material, Online to Continue to Complete Process Flow after Supply.
• Functions of curved aluminum frame and specially shaped frame (one side, both sides, triangle, quadrangle, hexagon, octagon, etc.)
• Output counting function, intelligent troubleshooting prompt.
