Product Details:
|
| Max Glass Size: | 2500*4500mm | Min Glass Szie: | 350*500mm |
|---|---|---|---|
| Glass Thickness: | 3-15mm | Glass Film Deleting Speed: | 15m/min |
| Grinding Wheel: | 10/12/15 | Machine Direction: | Let To Right /right To Left |
| Name: | Low-e Deleting Machine | ||
| Highlight: | glass making machine,double glazing glass machine |
||
Automatic low-e glass film removing machine for insulating glass production line
1, This equipment is specialized for low-e glass deleting edge with vertical structure and convenient production line connection.Transmission adopts imported servo control system, accurate positioning and smooth operation. High quality grinding wheels are durable and can produce neat and beautiful grinding crack. Distance can be set among 10 ~ 150 mm arbitrarily.
2.Auto measure the size and the thickness
3.Auto distinguish coating side of low-e glass(optional)
4.Auto-modified function
5.The pressure of edge deleting is stable and adjustable
6.Safety protection device auto-dedusting function
7.PLC control system,touch screen interface
8.Eight servo control systems
9.Control system intelligently memorize batch processing function
Main technical parameter
| Max.glass processing size | 2500*3500mm |
| Min.glass processing size | 350*500mm |
| Glass thickness | 3-19mm |
| Edge deleting width | 10-50mm |
| Glass conveyor speed: | 30m/min |
| Edge deleting speed | 0-15m/min |
| Abrasive wheel width | 10/12/15mm |
| Air supply | Flow 0.2m3/min |
| Air pressure | ≥0.8MPa |
| Total power | 3P 380V 50Hz 3.35KW |
| Dimension | 8000*2500*3400mm |
