High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass

High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass

Large Image :  High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass

Product Details:
Brand Name: LIJIANG
Model Number: LJTJ2540
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 65000

High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass

Description
NAME: Insulating Glass Machine Sealing Robot After-sales Service Provided: Engineers Available To Service Machinery Overseas
Min.glass Size: 300*300mm Max.glass Size: 2500*4000mm
Glass Thickness: 12-56mm Working Speed: 5-40m/min
Type: Automatic Machinery
High Light:

insulated glass equipment

,

glass making machine

Product Description

Insulating glass processing machine automatic sealing robot

LJTJ2540 is the latest automatic vertical insulating glass sealing robot. It is used to coat double glazed glass through mixing the A component and B component together according to a certain percentage. Applied to double/triple/shaped and stepped glasses (Optional) with stable performance and easy operation.

Technical data
Max.glass size
2500*4000mm
Min.glass size
300*300mm
Glass thickness
12-56mm
Working speed
5-40m/min
Air pressure
0.5-0.7MPa
Squeeze pressure
32MPa
Voltage power
380V 12kw
Overall dimension
8700*2000*3500mm

Main Features

1.Sealing glass edges and corners with smooth surface without air bubbles, no need to pare anything.
2.High automation and efficiency, suits to glass deep processing enterprise to use.
3.Eights famous servo control systems keep stable performance.
4.Synchronous belts make sure the glass being transferred smoothly with very accurate position.
5.All spare parts are produced with high standardization and precision, ensure the machine can be used in long term.
6. Automatically sealing DOUBLE / TRIPLE/ SHAPED/STEPPED insulating glass easily at once time with new technology.
7.All of the automatic functions are equipped with manual operations to prevent in case of failure.
8. Can storing three 3 pieces of IG (IG <1.8m) on the belts.
9. The device with high automation and efficiency is suitable to glass deep processing companies.
This equipment will always improve with the development of the glass market, and welcome to get kindly advice from you.

High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 0



Japanese YASKAWA motor

Adopt Japanese YASKAWA servo motor to control the sealing part with 360°rotating. Setting Scraper blade to scrape out extra glue without air bubbles and no need to repair glass corners by second time.



Intelligent sensor



Automatically recognize the glass size and glue width, allowing to adjust the coating speed online.





High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 1
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 2



Main electrical components



The main electrical components are adopted famous brands to maintain more stable performance, which comprise driver, PLC, input and output modules and so on.



Shaped glass (Optional)



With the development of updating technology, the sealing robot can coat eight shaped glasses according to the glass market.

High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 3
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 4



Stepped glass



For the stepped glass, it can be coated well by once time, don’t need to repair it on secondary.

Equipped with manual operation


Every separate part is equipped with manual operation, be easy to adjust in case.



High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 5
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 6

Details show

Withou air bubbles and coating evently in once time, no need to repair the corners.

Video Links:

www.youtube.com/watch?v=A27oJBE4g24

www.youtube.com/watch?v=ZEANB-BfV7E

Factory Workshop
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 7
Team
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 8
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 9
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 10
Contact person
Hermione (ME)
Tel
+86 13001733235
Whatsapp
+86 18353163989
Wechat
Lijiangglass01
Certifications
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 11
Exhibition Show
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 12
Our Service

After-sales service

*Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
* We are always online service you when your machine meets some problems.



Packing & Delivery
High Speed Insulating Glass Machine Sealing Robot For Double Glazed Glass 13
Packaging
Wooden box packing
When transfer to other countries in all over the world, the machine will be packed by wooden box.



Packaging Details
The normal package is wooden box. If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
