Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection

Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection
Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection
Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection

Large Image :  Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection

Product Details:
Place of Origin: CHINA
Brand Name: LIJIANG GLASS
Certification: CE
Model Number: CP-2500A
Payment & Shipping Terms:
Minimum Order Quantity: ONE
Price: $35,000 each
Packaging Details: Containers and wooden boxes
Delivery Time: 20 working days
Payment Terms: L/C, T/T
Supply Ability: 15 units per month
Contact Now

Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection

Description
Power: 42KW Weight: 3940KG
Voltage: 380V50HZ Dimension(L*W*H): 6260*4800*3100
Warranty: 1 Year Total Power: 3P 380V 50Hz
High Light:

Convenient Vertical Glass Washing Machine

,

Inspection Vertical Glass Washing Machine

,

low e glass drying machine

Glass washing machine technical parameters water tank outside, convenient water tank cleaning, change, inspection

Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection 0

Glass washing machine technical parameters CP-2500A

glass washing machine CP-2500A used for cleaning and drying the upper and lower surfaces of ordinary plate glass and high quality low-e glass,it is composed of incoming segment, cleaning air-drying segment and outgoing segment. 2, Structural characteristics: 1. Aluminum alloy assembled structure, no scrap concept, permanent use, high efficiency, energy saving 70% efficiency； 2. The rest of the sheet metal parts are sprayed with advanced mechanical paint or powder； 3. The rubber roller is made of vulcanized rubber with stainless steel shaft； 4. The washing part in contact with water is made of stainless steel； 5. Cleaning department, wind staff overall lift, the maximum lift: 350mm,easy to clean and maintain； 6. Three pairs of brush(Ø150mm)Stainless steel shaft configuration (low-e glass, ordinary coated glass and sunshine coated glass can be washed without damaging the coated surface)；
Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection 1



1. Aluminum alloy assembled structure, no scrap concept, permanent use, high efficiency, energy saving 70% efficiency； 2. The rest of the sheet metal parts are sprayed with advanced mechanical paint or powder； 3. The rubber roller is made of vulcanized rubber with stainless steel shaft； 4. The washing part in contact with water is made of stainless steel；
Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection 2



1. Cleaning department, wind staff overall lift, the maximum lift: 350mm,easy to clean and maintain； 2. Three pairs of brush(Ø150mm)Stainless steel shaft configuration (low-e glass, ordinary coated glass and sunshine coated glass can be washed without damaging the coated surface)； 3. Two pairs of special stainless steel aluminum alloy air knife configuration, strong wind, good air drying effect, with heating system(with temperature control device, optional opening and closing)；
Convenient Vertical Glass Washing Machine Water Tank Cleaning Change Inspection 3

Title goes here.

1. The fan is equipped with air filter in the air inlet chamber, with large air volume and good air drying effect,The whole fan box is installed in the upper part of the workshop, with the air filter screen on the side for easy inspection and cleaning； 2. Main drive for gear transmission, frequency control, digital display , the rotation of the brush roller in the washing section is driven by independent belts of the upper and lower motors respectively, the frequency conversion adjustment speed is stable, the service life is long, realizes the cleaning high request special glass；
Item.
Spec.
Maximum glass width
2500mm (effective maximum: 2650mm)
Minimum glass specification
400mm×400mm (limited to single row on left and right sides)
Glass thickness
3mm-25mm (digital display)
Speed range
glass thickness within 3-25mm Vmax=1-12m/min
Main drive, brush speed regulation
method
frequency control
Table height
900±25mm
Total power
42KW(water-bearing wind heating: 15KW)
Water source
self-circulation, tap water (according to civil water standards) and deionized water water supplement (deionized water equipment
shall be provided by the buyer)
Power source
380V 50Hz
Dimensions (length × width × height)
approximately 6260*4800*3100
Weight
3940kg
