Product Details:
|
| Speed: | 0-47m/min | Glass Thickness: | 1-40mm |
|---|---|---|---|
| Squeeze Pressure: | 10-18Mpa | Name: | Hotmelt Machine For Glass Butyl Extruder IG Glass Processing Machine |
| High Light: | double glass machine,hot melt butyl extruder |
||
|
Automatic filter function Automatically filter debris and air, keep spreading evenly. |
|
Special structure The special part controls both sides of nozzle opening and closing at the same time. |
|
Special material Belt Using non-adhesive belt, keep clean. |
|
Controllable pressing rollers (Optional) The wheels are used to pressing the spacer frames to keep the smooth running, |
|
When you coat spacers like the following decorative bars, you can choose to close this pressing rollers from the touch screen. |
Main features
PLC control system, touch screen interface
Automatically specify the width of the aluminum rod, which can be adjusted manually
The important part of the hydraulic system is by using German imported components to ensure that the plastic is full
Advance power on, increase work efficiency.
With warm function
With the inflatable exhaust function, improve the quality of sealing and save time for plastic
The fast coating speed can be up to 47m / min.
Saving the amount of glue
Company information
Jinan Lijiang Auto Equipment Co., Ltd (LIJIANG GLASS), located in the beautiful spring city ------ Jinan, is an enterprise that combines research and development of glass processing equipment, integrates sales and all services. Due to being close to the Beijing-Shanghai high-speed train, the transportation is very convenient.
The company is committed to building high-quality glass insulating machinery and equipment by learning from famous experts, establishing research and development centers, collaborating with famous organizations both at home and abroad, importing advanced technology and so on. Our friendly partners include North Glass, Xin Fuxing, Yaohua, Dalian Huaying, Beijing Guanhua, Shanghai Hao Jing, Sichuan Li Hehua and other famous companies.Since establishment, our products have been exported to Europe. America, South America, Middle East, Southeast Asia, India, almost 30 countries and regions At the same time, our company works with famous research institutes in the country, such as North China Industry Group, Shandong University and others, to continuously improve the level of technical research. So far, we have manufactured an automatic vertical IG production line with in-line gas filling, robot vertical seam welding machine, IG automatic bending machine, automatic desiccant filling machine and new automatic butyl extruder technology. And the quality has Reached the highest level in China
With the rapid development of the insulating glass industry, LIJIANG is looking forward to working with you for a win-win situation and together creating a new world.
| Squeeze pressure | 10-18MPa |
| Temperature | 110~140℃ |
| Aluminum spacer width | 4-30mm |
| Speed | 0-47m/min |
| Diameter of butyl cylinder | 200mm |
| Air supply | 0.4m³/min |
| Air pressure | ≥0.6MPa |
| Total power | 380V, 5KW, 50HZ |
| Dimension | 2600×680×1100mm(L×W×H) |
| Weight | 650kg |
