High Speed Coating Butyl Extruder Machine 47 M / Min For Shuttered Window Making

China High Speed Coating Butyl Extruder Machine 47 M / Min For Shuttered Window Making supplier

Large Image :  High Speed Coating Butyl Extruder Machine 47 M / Min For Shuttered Window Making

Product Details:

Place of Origin: Jinan China
Brand Name: Lijiang
Certification: CE
Model Number: LJTB01

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD 8000-13000/set
Packaging Details: Seaworthy plastic or plywood aviloble
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 sets/month
Contact Now
Detailed Product Description
Color: Customers' Request Coating Speed: 47m/min
Aluminum Spacer Size: 4-30mm Air Source: ≥0.6MPa
Supply Sealant Pressure: <100kg/cm2 Model: Automatic Machine
Automatic Machine: Insulating Glass Processing Function: Coating Butyl
Power: 5KW Voltage: 380V 50HZ

Butyl Coating Extruder Machine For Double Glass Making For Shuttered Window With Fast Coating Speed



LJTB01 Butyl Coating Extruder Machine For Double Glass Making For Shuttered Window With Fast Coating Speed is used to apply hot melt butyl to the aluminum spacers of insulating glass evenly. The use of large electrical control panel makes the operation easier. The conveyor of aluminum is controlled by frequency converter, and the speed can be adjusted from 0m/min to 47m/min. The squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable. The butyl extruder machine is energy-saving. The dispensing cylinder uses rotate supporting system and this makes the refill of butyl easier. The system can prolong the life of squeezing system and set the heating time in 24 hours with electricity and air pressure. The distance of squeezing head can be adjusted automatically according to different aluminum spacer. This Butyl Coating Extruder Machine For Double Glass Making For Shuttered Window With Fast Coating Speed has reached the worldwide technology with the characteristic of complete function and stable working mode.



Main Features

1.Auto-measure the width of spacer,so auto-adjust the distance of nozzle
2.Auto-centring and auto clamping
3.the bigger wheel help to coat the circular arc (curved spacer)
4.The wheel material is Teflon brand ,non-stick coating
5.The crossbeam height is easy to adjust,we can control the height of butyl
6.The coating speed is up to 47m/min,save butyl is up to 40%
7.Alarm device when out of butyl and easy to load butyl
8.Pre-heading function,set a regular time ahead of working time
9.Hydralic and pneumatic supercharging pump ,German Maxmator brand, German HAWE brand ,high pressure resistance ,keep the butyl well proportioned



Main Machine Data

Squeeze pressure 10-18MPa
Temperature 110~140℃
Aluminum spacer width 4-30mm
Speed 0-47m/min
Diameter of butyl cylinder 200mm
Air supply 0.4m³/min
Air pressure ≥0.6MPa
Total power 380V, 5KW, 50HZ
Dimension 2600×680×1100mm(L×W×H)
Weight 650kg



Machine details

High Speed Coating Butyl Extruder Machine 47 M / Min For Shuttered Window MakingHigh Speed Coating Butyl Extruder Machine 47 M / Min For Shuttered Window Making
