Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate

Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate
Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate
Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate

Large Image :  Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate

Product Details:
Place of Origin: Jinan
Brand Name: Lijiang
Certification: CE
Model Number: LJTJ2540
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: 65000 USD/SET
Packaging Details: Container
Delivery Time: 20 DAYS
Payment Terms: L/C, T/T
Supply Ability: 10 SETS/MONTH
Contact Now

Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate

Description
Name: Insulating Glass Automatic Sealing Rob Max.glass Size: 2500mm
Min.glass Size: 170mm*400mm (2000mm Machine) Glass Thickness: 12-56mm
Working Speed: 5-40m/min Air Pressure: 0.6-0.8MPa
Squeeze Pressure: <350kg/m³ Plane Angle: 6°- 9°
Max Glass Weight: 400kg Voltage Power: 380V 12kw
Overall Dimension: 8700mm*2000mm*3500mm
High Light:

Vertical Automatic Glass Sealing Robot

,

Insulating Automatic Glass Sealing Robot

,

Vertical Automatic Glass Sealing Robot

Vertical Insulating Glass Sealing Robot :

Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate 0

* Min & Max glass sizes can be optional
* Adopt 8 servo motors
* Adopt Japan ANCHUAN servo control systemwith stable performance
* Automaticallymeasure glass size, glue depth and glue speed with linear adjustment
* Adopt timingbelt to keep smooth convey with accurate position
* Sparesare produced with high standardization and high precision, ensure the machine can be used with long-term working
* The glass cornersare full without air bubbles, smooth surface, no need to
* Full automatic and high-efficiencymachine
* New scraper design, especially for making train IG with very even sides and corners, without any bubbles.
* Automatically repair glass corners with beautiful surface
* Smooth convey without scratchand pollution
* Single-function partsare equipped with manual functions, easy adjustment
* Shaped IG units (Optional)
* Stepped IG units with four sides (Optional)
* Double and Triple IG units
Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate 1


Parameter:


Item.
Spec.
Max.glass size
2500mm
Min.glass size
170mm*400mm (2000mm machine)
Glass thickness
12-56mm
Working speed
5-40m/min
Air pressure
0.6-0.8MPa
Squeeze pressure
<350kg/m³
Plane angle
6°- 9°
Max glass weight
400kg
Voltage power
380V 12kw
Overall dimension
8700mm*2000mm*3500mm





Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate 2

Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate 3

1.It can store three pieces of insulating glasses when glass sizes are less than 1.8m



2.With the development of updating technology, the sealing robot can coat 8 shaped glasses according to the glass market.



3.We put the machine head in the front,it will more convenient to making stepped IG units,It can connect with the IG line.



Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate 4






 Vertical Automatic Glass Sealing Robot For Insulating Glass IG Unit CE Certificate 5
