IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing
IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing

Large Image :  IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing

Product Details:
Place of Origin: JINAN CHINA
Brand Name: LIJIANG GLASS
Certification: CE
Model Number: LJTB01
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: wooden box
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 50 sets per month

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing

Description
Product Name: Butyl Glue Extrusion Coating Machine Application: Double Glazing Glass Processing
Heating Time: 15 Mins Squeeze Pressure: 10-25MPa
Speed: 0-47m/min Voltage: 380V 50Hz 3P
Squeeze Pressure: 10-18MPa Glue Thickness: 0.3-0.5mm
Aluminum Spacer Width: 5.5-26.5mm Weight: 750KG
High Light:

10MPa Butyl Extruder Machine

,

Double Glazing Butyl Extruder Machine

,

10mpa hot melt butyl machine

Good price IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing



Overview of butyl gule extrusion coating machine



LJTB01 Butyl Extruder is special equipment for the production of double-glazed glass. As one of the important equipment in the production of insulating glass, the effect of butyl glue is directly related to the waterproofing of the insulating glass. The equipment is automatic, easy to use, and convenient to use.



The glue butyl extrusion machine is used to evenly distribute the aluminum spacer frames with hot melt butyl. The operation of the butyl extruder is easier than before, it uses a large electric control panel. The aluminum conveyor is controlled by a frequency converter. The speed can be adjusted from 0m / min to 47m / min.





Tech parameters of high-speed butyl extruder machine



Squeeze pressure 10-25MPa
Temperature 110~140℃
Glue thickness 0.3-0.5mm
Glue width 3.5mm
Aluminum spacer width 5.5-26.5mm
Speed 5-47m/min
Diameter of butyl cylinder 200mm
Air supply 0.4m³/min
Air pressure ≥0.6MPa
Total power 380V, 5.7KW,50HZ
Dimension 2800×700×900mm(L×W×H)
weight7 50kg







Equipment details of automatic butyl coating machine



1.Germany Siemens parts

Adopt Siemens brand, stable performance.

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 0

3.Fast coating speed,can up to 47m/min

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 1

4.Germany HAVE Valve

Adopt Germany’s Harvey valve, more stable performance.

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 2

5.KINCO Touch Screen

Clear interface, Simple operation, Smart touch screen,Updated programming.

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 3

6.Alarm system

Automatically alarm system, reminding adding butyl.

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 4

7.Germany Maximator Cylinder

The supercharging system adopts famous pneumatic and hydraulic cylinder, control the pressure of outlet oil strongly.

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 5

8.Glue cylinder Adopt the upright structure, easy to change butyl.

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 6



Detail picture

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 7

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 8

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 9

Optional functions of butyl coating machine:



200L glue cylinder is optional



IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 10





Related Product



Automatic spacer bending machine LJZW2020



Automatic spacer bending machine is a special equipment for making aluminum frames of insulating glass, which replaces the traditional fabrication technology. This equipment can make a variety of convex polygonal aluminum frames by one aluminum strip in one time, thus strengthening the strength of the aluminum frame, making the sealing effect of the insulating glass more better.



Equipment details



  • Adopt Siemens PLC control system
  • There are 4 Siemens servos
  • Adopt 12 sets of racks which could store more different sizes of spacers. Use the Siemens servo to change different racks.
  • Automatically cut and feed aluminum spacers
  • Continuous bend shaped spacer frames
  • Automatically avoid connecting corner when bending and cutting
  • The machine grips the spacer from the top instead of gripping the spacer from the bottom, which solves the old-fashioned reversal problem.
  • Using industrial computer technology which could realize the drawing on the spot by the workers on the industrial computer and directly bend the drawn graphics.
  • The special machine hand device is used to fold the large spacer frame



Technical data



Max.bending size

2000mm*2000mm (2500mm*2500mm)

Min.bending size

250mm*200mm

Aluminum spacer width

5.5-27mm

Dimensional error

±0.5mm

Angle error

±1º

Processing speed

26s

Air supply

≥0.65MPa

Total power

AC220/380V 50Hz 2.5KW

Dimension

10500mm*2200mm*2600mm





Related product

1.Manual Gas Filling Machine LJCJ02N

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 11

Main feature

• It is used for filling Argon into insulating glass

• High effectively, allowed for four pieces of IGU

• When the gas is full,it will alarm and stop automatically

• Can set and display the data of gas value



Technical data



Power supply 220V 50Hz
Total power 0.1kw
Dimension 620*439*700mm

2.Cantilever crane LJXJ300

IGU 10MPa Butyl Extruder Machine Double Glazing Glass Processing 12

Technical data



Max.load 300kg
Rotated angle 90°
Upright height 3400mm or 3900mm
Rail length 1000mm
Quantity of sucker 2 or 4
Air pressure 0.5MPa-0.8MPa
