Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass

Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass
Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass

Large Image :  Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass

Product Details:
Place of Origin: China
Brand Name: LIijiang Glass
Certification: CE
Model Number: 2025
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 50000.00 - 55000.00
Packaging Details: Container/wooden box
Delivery Time: 45 days
Payment Terms: L/C, T/T
Supply Ability: 50sets/month

Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass

Description
Max.glass Size: 2000*2500mm Max.glass Size 2500*4000mm Min.glass Size: 300*300mm
Glass Thickness: 12-56mm Working Speed: 5-40m/min
Voltage Power: 380V 12kw
High Light:

2000mm*2500mm Insulating Glass Sealing Robot

,

Low E Insulating Glass Sealing Robot

,

2000mm*2500mm insulated glass sealing robot

Hot sale Automatic 2000mm*2500mm Insulating Glass Sealing Robot

Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 0
Details display

Main featureMain feature

Whole machine adopt man-machine interface, the operation is more convenient and intuition with the simplified thinking design interface.
The glass edge and corner is full without air bubbles, s
mooth surface, no need to pare the corner the condition that the glass are cut levelly and without dislocation after combined.
High automation, high efficiency, suitable for glass deep processing enterprise to use.
Can use two sets of independent sealant supply system( including the mixing device), two kinds of sealants switch in one-key operation easily.(optional)
Servo control system adopts world famous brand (Japan Anchuan), the performance is stable
Synchronous belt transmission to make the glass being transferred smoothly with accurate positioning
The spare parts are produced with high standardization and high precision, ensure the machine can be used with long-term stability.
Support three layer glass sealant
Automatic identification of glass size, glue, glue speed linear adjustment
Automatic angle correction function, appearance is beautiful
Alue supply system adopts Japan SMC cylinder, supply stability, the stability is good
Beautiful appearance generous, glass transfer smoothly no scratch, no pollution
Separate all equipped with manual functions, convenient adjustment
All size glass gluing fully at a time
It can glue the shapped glass , step glass .









Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 1

Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 2Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 3Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 4





Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 5 Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 6



Max.glass size
2500*4000mm
Min.glass size
300*300mm
Glass thickness
12-56mm
Working speed
5-40m/min
Air pressure
0.5-0.7MPa
Squeeze pressure
32MPa
Voltage power
380V 12kw
Overall dimension
8000*1500*2700mm
Dimension
10500mm*2200mm*2600mm







Certifications

Technician Team:

Technician Team: We have our own technician team ,IG line and automatic sealing robot technician team have 6 experts which all have more than 15 glass machine working experience. Aluminum spacer bending and desiccant filling machine team we have 3 technician which have rich experience in double glass machines. Butyl extruder machine and sealing pump and hot melt machine team have 4 experienced technician, all of them are worked in glass machine filed more than 12 years, Technician Team: We have our own technician team ,IG line and automatic sealing robot technician team have 6 experts which all have more than 15 glass machine working experience. Aluminum spacer bending and desiccant filling machine team we have 3 technician which have rich experience in double glass machines. Butyl extruder machine and sealing pump and hot melt machine team have 4 experienced technician, all of them are worked in glass machine filed more than 12 years,

  Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 7



Our service

Service Team:Service Team:

We have our own china domestic team and oversea service team . Whole team was included by 15 china engineers who worked in glass machine filed more than 20 years and 5 oversea engineers , two of them from india and others from south America and midle east. 24 hours online service and local engineer available , guarantee customers got timely service and solution .
Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 8Automatic 2000mm*2500mm Insulating Glass Sealing Robot Low E Glass 9
