Large Image :  Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing

Product Details:
Place of Origin: China
Brand Name: Jinan Lijiang Glass Machinery
Certification: CE & ISO9000
Model Number: LJCM2545 Smart Vertical Edge Deleting Machine
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Discussible
Packaging Details: Wooden Cases Package
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 15 sets per month

Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing

Description
Dimension(L*W*H): 22000x2000x3380mm Power: 25kw
Glass Thickness: 3-60mm Material: Stainless Steel
Voltage: 380V Air Pressure: 0.6-0.8Mpa
Max. Glass Size: 2000*2500mm Min. Glass Size: 300*450mm
High Light:

Glass Coating Insulating Glass Sealing Robot

,

Double Glazing Insulating Glass Sealing Robot

,

Sealant glass sealing machine

Automatic Insulating Glass Sealing Robot Sealant Glass Coating for Double Glazing Hollow Glasing Processing



Equipment Features:

1.The machine is suitable for glass deep processing enterprise, high automation, Reduce the labor intensity, save manpower, improve production efficiency
2.The Whole machine adopts a man-machine touch screen interface, with memory function.
3.After coating sealant, the glass edge and corner is full without air bubbles, smooth surface, no need to pare the corner
4. Using one/two sets of the independent sealant supply system, one/two kinds of sealants switch fast, in one-button operation easily (Model B), save time to change sealant.
5.The width of the machine is 1.5m, small floor area, save space
6. The sections is one production line, it can restore three pcs glass to improve the efficiency effectively
7.The smallest insulating glass size that can be processed is 300*450mm
8.Equipped with anti-blocking device in the mixer, easy to clean
9. Servo control system adopts world famous brand (Japan YASKAWA ), the performance is stable, counting speed is fast, sealant output with high precision, surface with high smoothness.
10. Shaft transmission to make the glass being transferred smoothly with accurate positioning.
11. Special V type transmission belt to avoid the sealant sticking on the belt, ensure the glass edge clean, V type Block is changeable
12. The key components are produced with high standardization and high precision, ensure the machine can be used with long-term stability
13.Suitable for triple glazing.
14.Conveying wheel on backboard adopts embedded wheel,to make sure the glass be transported smoothly
15.Equipped with a high-speed positioning function, glass can be located accurately when transport fast.







Benefits & Advantages

•Japan Yaskawa servo system control, fully automatic and high-efficiency sealing machine
•4 sections, can storage glass
•Adopt timing belt, smooth transfer, and accurate position
•Automatically repair glass corners with scraper and roller
•Automatically measure glass size, glue depth (30mm)
•Every auto-function is with manual operation
•Can coat double glass
•Shape glass with optional edges, step glass, triple glass (Optional)
•One set of booster pump controls two groups of sealants (Optional)
•Can use silicone, polysulfide, and silicone structural sealants
•Glue head is in the front of the machine, which is easy for coating step glass
•Can be connected with insulating glass processing line
•With code scanning function (Optional)
Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 0



The Smooth Glue Surface
After applying glue, It will ensure that the corners of the glass are full, without bubbles and other impurities, and the glue surface is so smooth.
Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 1



The High-precision Servo Control System
It adopts Japanese Yaskawa servo control system with clear wiring layout to ensure the stable overall performance of the equipment.
Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 2



The Glass Coating
Automatically measure glass size, glue depth, and glue speed through linear adjustment to ensure the stability of insulating glass coating quality.
Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 3



Glue Pump A and Glue Pump B
Equipped with a single A component and a single B component, mixed and glued. When applying glue, glue pump A and glue pump B are automatically mixed to realize automatic proportioning.



Equipment Parameter:

Input Voltage 50Hz 380V
Input Power 13 kW
Operation Air Pressure 0.6~0.8 MPa
Max. Glass Size 2000*2500mm
Min. Glass Size 300*450 mm
Working Speed 5-40m/min
Dimension 8600*1500*3100 mm
Weight 2500kg





More details Pictures



Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 4

Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 5

Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 6



Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 7

Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 8

Sealant Glass Coating Insulating Glass Sealing Robot For Double Glazing Hollow Glass Processing 9
