Easy Operating Glass Cantilever Crane 260kg-360kg With Lifting Sucker And Insulating Glass Processing Line

Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line
Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line

Large Image :  Easy Operating Glass Cantilever Crane 260kg-360kg With Lifting Sucker And Insulating Glass Processing Line

Product Details:
Place of Origin: China
Brand Name: Lijiang
Certification: CE
Model Number: LJXJ300
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable,
Packaging Details: wooden case or container
Delivery Time: 10days
Payment Terms: L/C, T/T
Supply Ability: 20set/month

Easy Operating Glass Cantilever Crane 260kg-360kg With Lifting Sucker And Insulating Glass Processing Line

Description
Name: Glass Cantilever Crane Advantage: With Lifting Sucker
Max Lifting Weight: 800KG
High Light:

45m/min insulating glass machine

,

15mm double glazing glass machine

,

Easy Operating Glass Cantilever Crane

Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 0



Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 1

Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 2

Glass Cantilever Crane with lifting sucker



1. This vacuum glass lifter is for handling insulating glass sheet.
2. This glass lifter is able to lift the glass sheet with 800kg
3. It is equip with 5 suckers. But the sucker can be add according to need of the client.
4. The equipment is Stable, Easy to use and safe.
5. The vacuum lifter is equipped with a warning light in case of a power failure or vacuum leakage, an optical and an acoustic signal goes off immediately to warn the operator to do emergency operation.



Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 3

Parameters:

Max Glass weight 260KG
Rotation angle Rotate 90 ° Left and right
Suction cups 2 pieces
Cups Materials Silicone
Sliding method Manual
Column height 4 meters Gas storage function
Arm length 4meters
Air control parts Airtac



Parameters:

Max Glass weight 360KG
Rotation angle 90° Left and Right
Suction cups 4 Pieces
Cups Materials Silicone
Sliding method Manual
Column height 4 meters Gas storage function
Arm length 4 meters
Air control parts Airtac

Useing For
- Insulating Glass Production line,
- Installing Glass Curtain Wall System,
- Loading and Unloading glass sheet on glass cutting table,
- Instaling car windscreen.



Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 4

Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 5

Jinan Lijiang Automation Equipment Co., Ltd. is located in the beautiful spring city------Jinan. It is an enterprise which integrated glass processing equipment research and development, sales and service into a whole world . As it is close to Beijing-Shanghai high-speed rail, the transportation is very convenient.



The company is committed to building high-end insulating glass machinery and equipment by learning from famous experts, establishing the research and development centers, cooperating with domestic and foreign well-known enterprises, importing advanced technology and so on. Now, our friendly partners include North Glass, Xin Fuxing, Yaohua, Dalian Huaying, Beijing Guanhua, Shanghai Hao Jing, Sichuan Li Hehua and other well-known enterprises. Since the establishment of the company, our products have been exported to Europe, America, South America, the Middle East, Southeast Asia, India, nearly 30 countries and regions. At the same time, our company worked with the well-known domestic research institutes, such as the North China Industrial Group, Shandong University and others, to constantly improve the level of technical research. So far, we have independently produced the vertical automatic IG production line with filling gas on line, the vertical IG sealing robot, the automatic spacer bending machine, the automatic desiccant filling machine and the new fully automatic butyl extruder machine, its technology and quality have reached the highest leading level in China.



With the rapid development of insulating glass industry, LIJIANG is looking forward to working with you for win-win situation and jointly creating a new world.





Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 6

Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 7Easy Operating Glass Cantilever Crane 260kg-360kg  With Lifting Sucker And  Insulating Glass Processing Line 8
